Sharp LC-19SK24U

117
Ref. No. Part No.
★
Description Code Ref
. No. Part No.
★
Description Code
LC-19SK24U/U-W
LC-19SB24U/U-W
LC-19SB14U
LC-19D44U
FB503 RBLN-A204WJZZY J Ferrite Bead AA
FB504 RBLN-A045WJZZY J Ferrite Bead AB
FB505 RBLN-A045WJZZY J Ferrite Bead AB
FB506 RBLN-A204WJZZY J Ferrite Bead AA
FB507 RBLN-A045WJZZY J Ferrite Bead AB
FB508 RBLN-A204WJZZY J Ferrite Bead AA
FB509 RBLN-A045WJZZY J Ferrite Bead AB
FB510 RBLN-A204WJZZY J Ferrite Bead AA
FB511 RBLN-A045WJZZY J Ferrite Bead AB
FB512 RBLN-A045WJZZY J Ferrite Bead AB
FB513 RBLN-A045WJZZY J Ferrite Bead AB
FB514 RBLN-A045WJZZY J Ferrite Bead AB
FB1101 RBLN-A021WJZZY J Ferrite Bead AA
FB1103 RBLN-A021WJZZY J Ferrite Bead AA
MISCELLANEOUS PARTS
J501 QJAKKA007WJZZ J Jack AG
J503 QTANZA050WJZZ J S Video Jack AG
J504 QJAKFA060WJZZ J Jack AD
J505 QJAKJA014WJZZ J Jack AD
P501 QCNCMA250WJZZ J Connector AE
P502 QCNCMA250WJZZ J Connector AE
P503 QCNCMA250WJZZ J Connector AE
TP501 QLUGHA002WJZZ J Lug AB
TP502 QLUGHA002WJZZ J Lug AB
TP503 QLUGHA002WJZZ J Lug AB
PSPAHB360WJ00 J Spacer AA
DUNTKE406WE01
R/C LED UNIT
INTEGRATED CIRCUIT
IC101 VHIMM1616++-1Y J MM1616XBRE AF
TRANSISTORS
Q102 VS2SC3928AR-1Y J 2SC3928AR AB
Q103 VS2SC3928AR-1Y J 2SC3928AR AB
Q107 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D103 RH-PX0421CEZZY J Diode AD
D115 RH-PX0421CEZZY J Diode AD
CAPACITORS
C102 RC-KZA069WJZZY J 4.7 10V Ceramic AB
C104 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C105 VCKYCY1HF103ZY J 0.010 50V Ceramic AA
RESISTORS
R101 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R102 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R104 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R108 VRS-CY1JF161JY J 160 1/16W Metal Oxide AA
R109 VRS-CY1JF821JY J 820 1/16W Metal Oxide AA
R122 VRS-CY1JF161JY J 160 1/16W Metal Oxide AA
R124 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R135 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P101 QPLGNA328WJZZY J Plug AD
RMC101 RRMCUA034WJQZ J Remote Receiver AE
DUNTKE407WE01(19SK24U/B24U/B14U/D44U)
DUNTKE407WE03(19SK24U-W/19SB24U-W)
SW UNIT
DIODES
D151 RH-EX0269TAZZY J Zener Diode, 15V AB
D152 RH-EX0269TAZZY J Zener Diode, 15V AB
DUNTKE241FM01
SUB UNIT (Continued)
D155 RH-EX0269TAZZY J Zener Diode, 15V AB
RESISTORS
R151 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R152 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R153 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R154 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
SWITCHES
S151 QSW-KA029WJZZY J Switch AD
S152 QSW-KA029WJZZY J Switch AD
S153 QSW-KA029WJZZY J Switch AD
S154 QSW-KA029WJZZY J Switch AD
S155 QSW-KA029WJZZY J Switch AD
S156 QSW-KA029WJZZY J Switch AD
S157 QSW-KA029WJZZY J Switch AD
MISCELLANEOUS PARTS
P151 QPLGNA324WJZZY J Plug AC
JBTN-A675WJ2A J Button AF
(LC-19SK24U/SB24U/SB14U/D44U)
JBTN-A675WJ2B J Button AF
LC-19SK24U-W/SB24U-W)
PZETKA238WJKZ J Barrier Sheet AD
QCNW-G523WJQZ J Connecting Cord AH
