2008-03-14
LC-19LE320, LC-22LE320, LC-26LE320, LC-32LE320, LC-37LE320, LC-42LE320
115
42” TROUBLESHOOTING TABLE
Power unit operation check.
LINE_FILTER_UNIT: YES
POWER_UNIT
YES
YES
YES
YES
YES
Are the power cord and harness in the unit properly connected?
NO
Connect the power cord and harness properly, and turn on the
p
ower.
Is F901/F902 normal?
NO
LINE_FILTER_UNIT:
Isn't RV901,C901,L901,C904,C902,C903,L902,RV903, etc. out
of order? Moreover, whether the short-circuit with the
circumference circuit is checked.
POWER_UNIT:
BD901, FB905, C910, etc. out of order?
Moreover, whether the short-circuit with the circumference circuit
is checked.
Is BD901 (+320V) output? (Set the main power SW to OFF.)
Does the PFC circuit operate normally?
(L906, Q901, D902, D903, IC901 and etc. And, the circuit around
the protection circuit etc. is checked.)
NO
Is a voltage of +5V applied to pin (12,13) of connector (CN902)?
(Set the main power SW to OFF.)
Does the switching circuit operate normally?
Check circuit around the primary side (T901, IC931, Q931,
ZD931, ZD930, ZD980, ZD981, etc.), the secondary side (D935,
L980, etc.), the AC_DET circuit (IC932, IC982, etc.), and the
protection circuit.
NO
Are +24V output as for the power on/off switch when it is on?
NO
Does the inverter circuit operate normally?
Check circuit around the primary side (T902,Q951,Q952,IC951,
D951,D952, etc.), the secondary side (D955, C943, etc.), and the
protection circuit.
Similarly, is +12V output as for the power on/off switch when it is
on?
NO
Check +12V circuit of D962, L931, etc.
Are +88V output as for the power on/off switch when it is on?
NO
Does the inverter circuit operate normally?
Check circuit around the second side (L907, Q991, D985, IC902,
Q903 etc.)
