Sharp LC-22LE320 User Manual

LC-19LE320, LC-22LE320, LC-26LE320, LC-32LE320, LC-37LE320, LC-42LE320
320
NO. PARTS CODE Sharp Code DESCRIPTION
CABINET PARTS(LC-37LE320E(AUO))
1 705TZA34168 9JR7050000260 BEZEL ASSY
2 078G120A 24 Y 9JR7800000028 SPEAKER 16 OHM 12W 600/320mm 130X30mm
3 750TVU370H4111N000 9JR7500000043 PANEL T370HW04 V1 TW AUO
4 CBPFA4ABP9 9JR9900000094 MAIN PCB ASSY(Nutune TUNER)
5 PTPFAPA3 9JR9900000076 RS232 PCB ASSY
6 ADTV7078PA1 9JR9900000091 POWER PCB ASSY
7 PTPFAPA2 9JR9900000075 MEMC PCB ASSY
8 P34T0473PAT 1T0100 9JR3400000022 REAR_COVER
9 KEPFAPA1 9JR9900000060 KEY PCB ASSY
10 705TZA3461A 9JR7050000146 KEY COVER ASSY
11 P34T0475PAT 1T0100 9JR3400000023 BASE_NECK
12 705TZA34167 9JR7050000259 BASE COVER ASSY
13 P15T0722101 BRACKET_BASE
14 IRPFAPA4 9JR9900000059 IR PCB ASSY
