LC-24LE150M
10 – 5
19
18
17
16
15
14
13
12
1110
R159
470
R154
10K
R158
150
R151
100
R152
10K
Q152
2SC3928AR
LED CONT
Q153
2SC3928AR
LED CONT
C157
10u
CKZ
C158
10u
CKZ
*D153
PXA194WJQZ
Green
D152
PXA193WJQZ
RED
RMC151
UA088WJ
123
1.0J (2012.08.29)
R/C.LED
0
0.2
0.7
0
2.3
0
