LC-24LE150M
5 – 1
CHAPTER 5. REMOVING OF MAJOR
PARTS
[1] REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1.Removing of the Rear Cabinet Ass'y and Stand Base
1 .Remove the 3 screws and detach the Stand Base
2 .Remove the 9 screws and detach the rear cabinet ass'y
1
3
2
4
3
1
2
3
4
