Sharp LC-24LE150M - Power Unit & LED;RC Unit Parts List

LC-24LE150M
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
D7001 RH-DXA198WJZZY AB V Diode
D7002 RH-DXA198WJZZY AB V Diode
D7003 RH-DXA198WJZZY AB V Diode
D7004 RH-DXA198WJZZY AB V Diode
D7005 RH-DXA095WJZZY AA V Diode
D7006 VHEZJ16B+++1EY AA V Diode
D7007 VHDBAV21///-1Y AA V Diode
D7009 VHDBAV21///-1Y AA V Diode
D7011 RH-DX0321CEZZY AA V Diode
D7012 RH-FXA014WJZZ AA V Diode
F7001 QFS-C3225CEZZ AC V 3.15A 250V
IC7001 VHINCP1251B-1Y AG V IC
IC7101 VHIKIA431A+-1+ AD V IC-KIA431A-AT/P
L7001 RCILFA388WJQZ AD V Coil
L7102 RCILPB497WJQZ+ AD V Coil
P7001 QPLGN0270GEZZ AA V -
P7101 QPLGNB198WJZZ AA V -
Q7001 VSKTA1535T+-1Y AA V Transistor KTA1535T-RTK/P
R7001 RR-HZ0041CEZZY AA V Fuse resistor
R7002 VRS-CY1JF122JY AA V Resistor 1.2k 1/16w Metal Oxide
R7003 VRD-RA2BE224JY AA V Resistor 220k 1/8w Carbon
R7004 VRS-CY1JF474JY AA V Resistor 470k 1/16w Metal Oxide
R7005 VRS-TV1JD224JY AA V Resistor 220k Metal Oxide
R7007 VRS-TV1JD000JY AA V Resistor 0 Metal Oxide
R7008 VRS-CY1JF102JY AA V Resistor 1k 1/16w Metal Oxide
R7009 VRS-TV1JD220JY AA V Resistor 22 Metal Oxide
R7011 VRS-RG3DB223J+ AA V Resistor 22k 2w Metal Oxide
R7012 VRS-CY1JF223JY AA V Resistor 22k 1/16w Metal Oxide
R7014 VRN-RL3DBR68J+ AA V Resistor 68 2w Metal Oxide
R7015 VRN-RL3DBR47J+ AA V Resistor 47 2w Metal Oxide
R7016 RR-HZ0014GEZZY AA V Fuse resistor
R7017 VRD-RA2BE393JY AA V Resistor 39k 1/8w Carbon
R7018 VRD-RA2BE470JY AA V Resistor 47 1/8w Carbon
R7019 VRD-RA2BE470JY AA V Resistor 47 1/8w Carbon
R7101 VRS-CY1JF182JY AA V Resistor 1.8k 1/16w Metal Oxide
R7102 VRS-CY1JF152JY AA V Resistor 1.5k 1/16w Metal Oxide
R7104 VRS-CY1JF822FY AA V Resistor 8.2k 1/16w Metal Oxide
R7105 VRS-CY1JF682FY AA V Resistor 6.8k 1/16w Metal Oxide
R7106 VRS-CY1JF562FY AA V Resistor 5.6k 1/16w Metal Oxide
R7107 VRS-CY1JF123FY AA V Resistor 12k 1/16w Metal Oxide
R7108 VRS-CY1JF223JY AA V Resistor 22k 1/16w Metal Oxide
R7114 VRS-CY1JF470JY AA V Resistor 47 1/16w Metal Oxide
R7115 VRS-CY1JF470JY AA V Resistor 47 1/16w Metal Oxide
R7117 VRS-CY1JF122JY AA V Resistor 1.2k 1/16w Metal Oxide
RJ7003 QJUM-0001AJFWY V JUMPER
RJ7004 QJUM-0001AJFWY V JUMPER
RJ7005 QJUM-0001AJFWY V JUMPER
RJ7006 QJUM-0001AJFWY V JUMPER
RJ7009 QJUM-0001AJFWY V JUMPER
RJ7021 QJUM-0001AJFWY V JUMPER
RJ7023 QJUM-0001AJFWY V JUMPER
RJ7101 QJUM-0001AJFWY V JUMPER
T7001 RTRNWA431WJPZ AN V Transformer
TH7001 RH-HXA049WJZZ AD V Thermistor
VA7001 RH-VXA182WJN1 AC V Varistor
[5] LED / RC UNIT ( DUNTKG265FM02 )
C157 RC-KZA237WJZZY AB V Capacitor
C158 RC-KZA237WJZZY AB V Capacitor
D152 RH-PXA193WJQZY AB V Diode
D153 RH-PXA194WJQZY AB V Diode
P151 QPLGNB150WJZZY AA V -
Q152 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
Q153 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
R151 VRS-CZ1JF101JY AA V Resistor 100 1/16w Metal Oxide
R152 VRS-CZ1JF103JY AA V Resistor 10K 1/16w Metal Oxide
R154 VRS-CZ1JF103JY AA V Resistor 10K 1/16w Metal Oxide
R158 VRS-CZ1JF151JY AA V Resistor 150 1/16w Metal Oxide
R159 VRS-CZ1JF471JY AA V Resistor 470 1/16w Metal Oxide
RMC151 RRMCUA088WJZZ AE V IR Receiver HM238R-W4
[6] HEAT SINK ASSEMBLY (CRDARB103WE03)
D 7103 VHDMBR10U15-G V Diode
RDA7101 PRDARB109WJFW V Radiator
LX-BZ3100CEF7 V Screw
ZGLYC-10-R20E - Grease
[7] HEAT SINK ASSEMBLY (CRDARB103WE04)
Q 7002 VSKF10N68F+-G Transistor
RDA7001 PRDARB109WJFW Radiator
LX-BZ3100CEF7 Screw
ZGLYC-10-R20E - Grease
[4] POWER UNIT ( DUNTKG255FM02 )
