Sharp LC-26D44 - Software Updating Procedures; VCTPro Software Update Methods; Digital Board Software Update

Training course: D44
23
SEES Engineering Department
3. Software Updating
HOW TO UPDATE THE SOFTWARE
VCTPro SOFTWARE UPDATE
There are 4 methods to update software in the VCTpro:
• RS-232C HyperTerminal Method
• RS-232C Tera Term Method
NOTE: (RS-232C method is allowed when the TV is working properly and the action should be only software upgrade)
• I2C Method
• PCMCIA Card Method (NEW!!)
DIGITAL SOFTWARE UPDATE
There are 2 methods to update the Digital Board Software on Flash Memory (IC4203) throught the Digital Processor
(IC4001):
• PCMCIA CARD (Compact Flash Memory) Method
NOTE: The PCMCIA method is only compatible with those PCs running XP Windows Version.
• Jig RS-232 WinUpload Method (From PC through RS-232C COM port)
