LC-32/37D43U
2 – 3
QUICK REFERENCE
2
1 3
Hex key
Screw
Insert the stand into the openings on the
bottom of the TV.
Insert and tighten the 4 screws into the 4
holes on the rear of the TV.
Hex key
Screw
Soft cushion
NOTE
To detach the stand, perform the steps in reverse order.
Set the post for the stand unit onto the
box.
Attach the base to the post.
Insert and tighten the 5 screws into the 5
holes on the bottom of the base.
Confirm that there are 9 screws (all the same
size) supplied with the TV.
Attaching the stand
Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
Attach the stand in the correct direction.
Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
To Next Page
