105
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
INTEGRATED CIRCUITS
IC2001 VHiBD4742G+-1Y J BD4742G-TR AD
IC2002 RH-iXA757WJN1Y J M24128-BWMN6T AN
IC2003 VHiLTC1694C-1Y J LTC1694CS5#TR AM
IC2004 RH-iXA870WJZZQ J HD64F3687H AY
IC2008 VHiBR24C08F-1Y J BR24C08F-E2 AF
IC2010 VHiM62392FP-1Y J M62392FP AM
IC2014 VHiTC7W34U/-1Y J TC7W34FU AE
IC2015 VHiSN2G66CT-1Y J SN74AHC2G66HDC AE
IC2016 VHiLVX125FT-1Y J TC74LVX125FT AG
IC2017 VHiLVX125FT-1Y J TC74LVX125FT AG
IC4101 RH-iXA706WJZZQ J IR3E12M1 AN
IC4102 VHiNJM4580V-1Y J NJM4580V AE
IC4107 VHiLP2951CM-1Y J LP2951CMX AL
IC4108 VHiPQ1CZ41H-1Y J PQ1CZ41H2ZP AG
IC4109 VHiLT1615ES-1Y J LT1615ES5 AP
IC4114 VHiLT1617ES-1Y J LT1617ES5 AP
IC4116 VHiLTC1872+-1Y J LTC1872ES6 AR
IC4501 RH-iXA865WJZZQ J I.C. BH
IC4502 VHiTC7W34U/-1Y J TC7W34FU AE
IC4503 VHiTC7W34U/-1Y J TC7W34FU AE
IC4505 RH-iXA866WJN3Y J I.C.(LC-37G4U/G4D) AY
IC4505 RH-iXA962WJN3Y J I.C.(LC-32G4U/G4D) AY
IC4506 VHiPST3629N-1Y J PST3629NR AD
IC4601 VHiPQ1R33//-1Y J PQ1R33 AE
IC4602 VHiTLVD824+-1Q J THC63LVD824 AY
IC4701 RH-iXA332WJZZQ J XC2S150-5PQ208 BM
IC4702 RH-iXA312WJN1Q J MT48LC2M32B2TG AX
IC4901 RH-iXA332WJZZQ J XC2S150-5PQ208 BM
IC4902 RH-iXA312WJN1Q J MT48LC2M32B2TG AX
IC7701 VHiAN8005M/-1Y J AN8005M AD
IC7702 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC7703 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC7704 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC7705 VHiBD4742G+-1Y J BD4742G-TR AD
IC7706 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC7709 VHiBD4742G+-1Y J BD4742G-TR AD
IC7710 VHiPQ015YZ5-1Y J PQ015YZ5MZP AF
IC7711 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
TRANSISTORS
Q2001 VSDTC114EE/-1Y J DTC114EE AB
Q2002 VSDTC144EE/-1Y J DTC144EE AA
Q2003 VSDTC144EE/-1Y J DTC144EE AA
Q2004 VSDTC144EE/-1Y J DTC144EE AA
Q2005 VS2SK536///-1Y J 2SK536 AE
Q2006 VS2SK536///-1Y J 2SK536 AE
Q2007 VS2SC3928AR-1Y J 2SC3928AR AB
Q2008 VS2SA1530AR-1Y J 2SA1530AR AB
Q2009 VSDTC144EE/-1Y J DTC144EE AA
Q2010 VSDTC114EE/-1Y J DTC114EE AB
Q2012 VSDTC144EE/-1Y J DTC144EE AA
Q2013 VS2SK536///-1Y J 2SK536 AE
Q2014 VS2SK536///-1Y J 2SK536 AE
Q4101 VS2SD1664Q+-1Y J 2SD1664Q AC
Q4103 VS2SA1530AR-1Y J 2SA1530AR AB
Q4104 VS2SC3928AR-1Y J 2SC3928AR AB
Q4105 VSTP0610T++-1Y J TP0610T AD
Q4106 VS2SC3928AR-1Y J 2SC3928AR AB
Q4108 VS2SK1826++-1Y J 2SK1826 AC
Q4109 VS2SK1826++-1Y J 2SK1826 AC
Q4110 VSSi4884DY+-1Y J SI4884DY-T1 AG
Q4112 VS2SB1132Q/-1Y J 2SB1132Q AC
Q7702 VSDTA114EE/-1Y J DTA114EE AB
Q7703 VSDTC114EE/-1Y J DTC114EE AB
DIODES AND LED'S
D2002 VHD1SS355//-1Y J 1SS355 AB
D2003 VHD1SS355//-1Y J 1SS355 AB
D2004 VHDMA157A//-1Y J MA157A AC
D2005 VHD1SS355//-1Y J 1SS355 AB
D4101 VHDHSU119//-1Y J HSU119 AB
D4102 VHDSFPB74//2EY J SFPB74 AD
D4103 VHDHSU119//-1Y J HSU119 AB
D4104 VHDHSU119//-1Y J HSU119 AB
D4105 VHDSFPB54//2EY J SFPB54 AC
D4106 RH-EX1274CEZZY J Zener Diode AB
D4107 VHDHSU119//-1Y J HSU119 AB
D4108 VHDSFPB54//2EY J SFPB54 AC
D4109 VHDSFPB74//2EY J SFPB74 AD
D4110 VHDDA221///-1Y J DA221 AB
D4501 VHDDAN222//-1Y J DAN222 AA
D4601 VHD1SS355//-1Y J 1SS355 AB
D7703 VHDHSU119//-1Y J HSU119 AB
D7704 VHDSFPB54//2EY J SFPB54 AC
D7705 VHDSFPB54//2EY J SFPB54 AC
D7707 VHDSFPB54//2EY J SFPB54 AC
D7710 VHDHSU119//-1Y J HSU119 AB
D7711 VHDDAN222//-1Y J DAN222 AA
D7712 VHDSC8024//-1Y J SC8024 AC
D7713 VHDSC8024//-1Y J SC8024 AC
D7714 VHDSFPB54//2EY J SFPB54 AC
D7715 VHDDAN222//-1Y J DAN222 AA
PACKAGED CIRCUITS
X2001 RCRSC0032TAZZY J Crystal AG
X4501 RCRSZA025WJZZY J Crystal AM
FILTERS
FL2001 RFiLZ0169TAZZY J Filter AD
FL4103 RFiLNA002WJZZY J Filter AD
FL4651 RFiLNA002WJZZY J Filter AD
FL4652 RFiLNA002WJZZY J Filter AD
FL4653 RFiLNA002WJZZY J Filter AD
FL4654 RFiLNA002WJZZY J Filter AD
COILS
L4101 RCiLP0343TAZZY J Coil AD
L4102 RCiLP0402CEZZY J Coil AF
L4103 RCiLP0355TAZZY J Coil AD
L4104 RCiLP0343TAZZY J Coil AD
L4105 VPD9M4R7J1R4NY J Peaking, 4.7µH AB
L4106 RCiLPA001WJZZY J Coil AF
L4107 VPBWM220K1R2NY J Peaking, 22µH AC
L4108 VPBWM220K1R2NY J Peaking, 22µH AC
L4109 RCiLP0343TAZZY J Coil AD
L4110 VPD9M4R7J1R4NY J Peaking, 4.7µH AB
L7701 RCiLP0343TAZZY J Coil AD
L7702 RCiLP0303TAZZY J Coil AG
L7704 RCiLP0301TAZZY J Coil AF
L7707 RCiLP0343TAZZY J Coil AD
L7708 RCiLP0343TAZZY J Coil AD
L7710 RCiLP0343TAZZY J Coil AD
L7711 RCiLP0305TAZZY J Coil AE
L7712 RCiLP0305TAZZY J Coil AE
L7713 RCiLP0343TAZZY J Coil AD
CAPACITORS
C2001 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2003 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2004 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2005 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2006 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2007 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2009 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2010 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2012 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2013 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2014 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2015 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2016 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2017 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2019 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2020 VCKYCY1HB103KY J 0.01 50V Ceramic AA
DUNTKC268VJ04 (LC-32G4U/G4D)
DUNTKC268VJ03 (LC-37G4U/G4D)
LCD CONT Unit
