Sharp LC-32LD164E Service Manual

42
LC-32LD164
LC-32LD165
LC-32LD166
2838 100 05424
TPV
2K14 SHARP EU/EU_2G/UK Family
TYPE
:
BRAND
:
Yolin Chen
170 4
Example :
1. PC Connected to ISP board (By USB cable).
2. a) Method one: ISP board connected to TV (By UART cable).
Or b) Method two: ISP board connected to TV (By HDMI cable).
I. Double click FlashTool.exe to start.
II. Set (MT53XX → RS232 → COM_Port
→ 115200 → Connect → FW_Upgrade
→ Nor Flash).
(Hint: In above RED highlight section, if your TV is SHARP_EU &
SHARP_EU_2G you must select Nor Flash, and if your TV is SHARP_UK, you
must select Nand Flash)

Sharp LC-32LD164E Specifications

General

Brand	Sharp
Model	LC-32LD164E
Category	LCD TV
Language	English
