Sharp LC-32LD164E Service Manual

90
LC-32LD164
LC-32LD165
LC-32LD166
REF No. PARTS DESCRIPTION *
PRICE
CODE
R130 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R131 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R132 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R133 061G04027509FY RST CHIP 75R 1/16W 1% - --
R134 061G0402513 JT RST CHIP 51K 1/16W 5% TZAI YUAN - --
R135 061G04027509FY RST CHIP 75R 1/16W 1% - --
R136 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R137 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R138 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R139 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN - --
R140 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R143 061G0402303 JY RST CHIP R 30KOHM 1/16W +/-5% YAGEO - --
R144 061G0402303 JY RST CHIP R 30KOHM 1/16W +/-5% YAGEO - --
R146 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN - --
R147 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R149 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R150 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R151 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R154 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R155 061G04021000FT RST CHIP 100R 1/16W 1% - --
R156 061G04021500FT RST CHIP 150R 1/16W 1% - --
R157 061G04021000FT RST CHIP 100R 1/16W 1% - --
R159 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA - --
R160 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA - --
R162 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R165 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R180 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN - --
R192 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R193 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R194 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R195 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R197 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R198 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN - --
R199 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R402 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R404 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R406 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R407 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R410 061G0402104 JY RST CHIPR 100KOHM +-5% 1/16W YAGEO - --
R411 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R412 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R414 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R416 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R418 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R420 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R421 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R422 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R423 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R425 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R427 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA - --
R430 061G04024701FF RST 0402 4.7K 1% 1/16W - --
R431 061G04024701FF RST 0402 4.7K 1% 1/16W - --
R432 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN - --
R433 061G04021000FT RST CHIP 100R 1/16W 1% - --
R434 061G04021000FT RST CHIP 100R 1/16W 1% - --
R435 061G04021000FT RST CHIP 100R 1/16W 1% - --
R436 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN - --
R437 061G04021000FT RST CHIP 100R 1/16W 1% - --
R438 061G04021000FT RST CHIP 100R 1/16W 1% - --
R439 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA - --
R440 061G06034701FY RST CHIP 4K7 1/10W 1% - --
R441 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R444 061G04021001FY RST CHIP 1K 1/16W 1% - --
R448 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R455 061G04021001FY RST CHIP 1K 1/16W 1% - --
R456 061G04023302FY RST CHIP 33K 1/16W 1% - --
R457 061G04022400FF RST CHIPR 240 OHM +-1% 1/16W FENGHUA - --
REF No. PARTS DESCRIPTION *
PRICE
CODE
R460 061G04022202FT RST CHIP 22K 1/16W 1% TZAI YUAN - --
R461 061G04021001FY RST CHIP 1K 1/16W 1% - --
R464 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R465 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R466 061G06036042FF RST 0603 60.4K 1% 1/10W FENGHUA - --
R467 061G04024022FF RST CHIP 40.2K 1/16W 1% FENGHUA - --
R468 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R470 061G06031800FY RST CHIP 180R 1/10W 1% - --
R471 061G06038209FT RST CHIP 82R 1/10W 1% TZAI YUAN - --
R473 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R474 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R476 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R477 061G04021602FT RST 0402 16K 1% 1/16W - --
R479 061G04022202FT RST CHIP 22K 1/16W 1% TZAI YUAN - --
R480 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R501 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R502 061G0402104 JY RST CHIPR 100KOHM +-5% 1/16W YAGEO - --
R503 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN - --
R504 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R505 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R506 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN - --
R507 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN - --
R508 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN - --
R509 361G0402911AJF RST 0402 910R 5% 1/16W RC-02W911JT - --
R510 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R511 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R512 061G0402750 JY RST 0402 75R 5% 1/16W RC0402JR-0775RL - --
R513 061G0402104 JY RST CHIPR 100KOHM +-5% 1/16W YAGEO - --
R514 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R519 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R520 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN - --
R524 361G0402911AJF RST 0402 910R 5% 1/16W RC-02W911JT - --
R525 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R560 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN - --
R561 061G0402750 JY RST 0402 75R 5% 1/16W RC0402JR-0775RL - --
R601 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --
R602 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --
R603 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --
R604 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --
R605 061G0603180 JT RST CHIP 18R 1/10W 5% TZAI YUAN - --
R606 061G0603180 JT RST CHIP 18R 1/10W 5% TZAI YUAN - --
R607 061G0603180 JT RST CHIP 18R 1/10W 5% TZAI YUAN - --
R608 061G0603180 JT RST CHIP 18R 1/10W 5% TZAI YUAN - --
R609 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R610 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN - --
R611 061G04021001FY RST CHIP 1K 1/16W 1% - --
R612 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN - --
R613 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R614 061G04021822FF RST CHIPR 18.2KOHM +-1% 1/16W FENGHUA - --
R615 061G0402273 JF RST CHIP 27K 1/16W 5% FENGHUA - --
R616 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R617 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R618 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R620 061G0402273 JF RST CHIP 27K 1/16W 5% FENGHUA - --
R622 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R623 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R625 061G0603100 JF RST CHIPR 10 OHM 5% 1/10W FENGHUA - --
R626 061G0603100 JF RST CHIPR 10 OHM 5% 1/10W FENGHUA - --
R655 061G0402330 JT RST CHIP 33R 1/16W 5% TZAI YUAN - --
R657 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R658 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R659 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA - --
R660 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA - --
R664 061G04021001FY RST CHIP 1K 1/16W 1% - --
R668 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN - --
R669 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN - --
R672 061G04025101FT RST CHIP 5.1K 1/16W 1% TZAI YUAN - --
