Sharp LC-32LD164E Service Manual

92
LC-32LD164
LC-32LD165
LC-32LD166
REF No. PARTS DESCRIPTION *
PRICE
CODE
L401 373G0806229CNM CHIP IND 2.2UH 30% 1.2A 0.15R MGFL2016F - --
L601 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L602 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L603 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L604 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L701 373G0806229CNM CHIP IND 2.2UH 30% 1.2A 0.15R MGFL2016F - --
L702 373G253S144DN0 SMD CHOKE 0.47UH 20% 20 0.0035R -- - --
L703 073G253S 88 M SMD CHOKE 15UH 20% 0.568R 2.8A - --
FB101 071G 56A221 M CHIP BEAD 0805 220R/2000MA - --
FB102 371G042P121M02 CHIP BEAD 0402 120R 25% MGLB1005M121T1R3 - --
FB105 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB106 071G 56A221 TA IND FXD 0805 EMI 100MHZ 220R R - --
FB401 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB403 071G 59C300 TA CHIP BEAD 0603 30R 25% FCM1608CF-300T06 - --
FB404 071G 56A221 TA IND FXD 0805 EMI 100MHZ 220R R - --
FB405 071G 59S121 M HIP BEAD 120R/500MA - --
FB407 371G042P121M02 CHIP BEAD 0402 120R 25% MGLB1005M121T1R3 - --
FB409 371G042P121M02 CHIP BEAD 0402 120R 25% MGLB1005M121T1R3 - --
FB410 371G042P121M02 CHIP BEAD 0402 120R 25% MGLB1005M121T1R3 - --
FB501 071G 59S121 M HIP BEAD 120R/500MA - --
FB503 071G 59S121 M HIP BEAD 120R/500MA - --
FB602 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB603 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB604 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB605 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB606 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB607 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB608 071G 59S121 M HIP BEAD 120R/500MA - --
FB609 071G 59S121 M HIP BEAD 120R/500MA - --
FB701 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB702 071G 56A221 TA IND FXD 0805 EMI 100MHZ 220R R - --
FB703 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB704 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB706 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
TU101 394G0DVB00T31Y TUNER EUROPE SUT-RE231TN P AQ
C101 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C102 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C103 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C104 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C1043 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C105 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C106 065G040215232KY CAP CHIP 0402 1.5NF 50V X7R - --
C107 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C108 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C109 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C110 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C111 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C112 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C113 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C114 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C115 065G060322515KA 0603 2.2UF K 16V X5R - --
C116 065G060322515KA 0603 2.2UF K 16V X5R - --
C117 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C118 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C119 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C120 065G040233131JA MLCC 0402 330PF 50V NP0 +-5% - --
C121 065G040247031JY CAP 0402 47PF 5% 50V NP0 - --
C123 065G040247031JY CAP 0402 47PF 5% 50V NP0 - --
C124 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C125 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C126 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
TUNER
CAPACITORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
C127 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C128 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C129 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C130 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C131 065G040247131JA CAP CHIP 0402 470PF J 50V NPO - --
C132 065G060322515KA 0603 2.2UF K 16V X5R - --
C134 065G060322515KA 0603 2.2UF K 16V X5R - --
C135 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C136 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C137 065G040247131JA CAP CHIP 0402 470PF J 50V NPO - --
C139 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C141 067G305M1013CV EC 100UF 20% 16V 6.3*7 - --
C142 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C143 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C144 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C145 065G040222322KY CAP 0402 22NF 10% 25V X7R - --
C148 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C149 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C152 065G060310512KM CAP 0603 1UF 10% 16V X7R GRM188R71C105K - --
C153 065G040222031JT CAP 0402 22PF 5% 50V NP0 UMK105 CG220JV - --
C154 065G040222031JA CAP 0402 22PF J 50V NPO - --
C155 065G040222031JA CAP 0402 22PF J 50V NPO - --
C156 065G060310512KM CAP 0603 1UF 10% 16V X7R GRM188R71C105K - --
C157 065G040222031JT CAP 0402 22PF 5% 50V NP0 UMK105 CG220JV - --
C158 065G040215031JF CAP 0402 15PF J 50V NPO - --
C159 065G040215031JF CAP 0402 15PF J 50V NPO - --
C160 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C161 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C162 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C163 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C164 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C165 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C166 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C167 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C169 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C170 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C171 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C172 065G0805106A5KA CAP 0805 10UF 10% 10V X5R - --
C173 065G0805106A5KA CAP 0805 10UF 10% 10V X5R - --
C174 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C177 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C186 065G0805106A5KA CAP 0805 10UF 10% 10V X5R - --
C190 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C191 065G040222031JA CAP 0402 22PF J 50V NPO - --
C192 065G040222031JA CAP 0402 22PF J 50V NPO - --
C194 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C402 065G0603475A5KA CAP 0603 4.7UF 10% 10V X5R CL10A475KP8NN - --
C403 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C404 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C405 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C406 065G040215031JF CAP 0402 15PF J 50V NPO - --
C407 065G040215031JF CAP 0402 15PF J 50V NPO - --
C408 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C409 367G315M1013AV EC 100UF 20% --16V ---- -- --ERF1CM101 - --
C410 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C411 065G060347412KF CAP 0603 470NF 10% 16V X7R - --
C412 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C414 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C415 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C416 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C418 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C419 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C426 065G080522605MT CAP 0805 22UF 20% 6.3V X5R JMK212 BJ226 - --
