Sharp LC-32LD164E Service Manual

96
LC-32LD164
LC-32LD165
LC-32LD166
REF No. PARTS DESCRIPTION *
PRICE
CODE
R728 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --
R729 061G04028202FT RST 0402 82K 1/16W 1% TZAI YUAN - --
R730 061G04021802FT RST CHIP R 18KOHM 1/16W +/-1% - --
R732 061G04021802FT RST CHIP R 18KOHM 1/16W +/-1% - --
R734 061G06032492FT RST 0603 24.9K 1% 1/10W TZAI YUAN - --
R735 061G04023301FF RST CHIP 3K3 1/16W 1% FENGHUA - --
R744 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN - --
R745 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN - --
R746 061G0805000 JT RST 0805 0.05R MAX 1/8W - --
R765 061G0402105 JF RST CHIPR 1MOHM 5% 1/16W FENGHUA - --
CI-U402 370G0KEYCI5561 CD PANASONIC 2K14 MT5561 PLATFORM CI+ - --
CN103 388G352F6B3AXH00HF USB A TYPE 319AFKD21BNHF 6P 1*1 BLACK - --
CN116 088G 78F154XCL RCA JACK V/T 12P G/BL/R/W/R 1*5 H=8.6 - --
CN151 388G355HLB1VYG SCART V/T 21P 1*1 BLACK 8.4 - --
CN159 088G 50019F VA PCMCIA R/A 68P 1*1 BLACK 8MM - --
CN401 033G3802 8B YH L CONNECTOR 8P 2.0 - --
CN402 033G3802 3 2006F19252M 3P - --
CN408 311GW200C34ABL WAFER 2.0MM 34P R/A B2000W34HTKA - --
CN501 088G 34021A VA HDMI V/T 21P 1*1 BLACK 10.5MM - --
CN502 088G 34021A VA HDMI V/T 21P 1*1 BLACK 10.5MM - --
CN601 311GW200A04ABX WAFER 2.0MM 4P - --
CN602 088G302G7B1ACL PHONE JACK R/A 7P BLACK H=10.5 - --
CN603 088G 359 10 JT FIBER-OPTIC JACK V/T 3P BLACK H=8.5 - --
CN701 311GW250B14BBX WAFER 2.5MM 14P W2415-14RVA-S01-A - --
GND1 009G6005 1 GND TERMINAL - --
GND2 009G6005 1 GND TERMINAL - --
GND3 009G6005 1 GND TERMINAL - --
GND4 009G6005 1 GND TERMINAL - --
HDCP-U406 070GHDCP500HDC HDCP CODE - --
SH1 P90T0059202 HEAT SINK - --
SH2 Q90G0198 1 HEAT SINK - --
U101 356G0575048049 DEMODULATOR CXD2837ER-T4 VQFN 48 - --
U113 056G 563114 LDO G1117-33T63UF 1A 3.3V SOT-223 - --
U401 356G0568329602 SCALER MT5561PUDT /B BGA-329 - --
U403 056G 665528 OTHERS IC G5250M1T1U 1A SOT23-5 - --
U404 056G 665528 OTHERS IC G5250M1T1U 1A SOT23-5 - --
U405 356G3333001009 FLASH TC58NVG0S3HTAI0_REV0.20_E120706C - --
U406 056G1133 83 1 IC M24C64-WMN6P 64K SO-8 ST - --
U410 056G74LS 4 IC 74CBTLV1G125GW SOT353-1 - --
U411 356GD563005123 DC/DC G5695T11U 1 6V SOT-23-5 - --
U414 356G74LS016064000C LOGIC 74HC4052PW (CU) TSSOP-16 - --
U501 056G 662 21 ESD PROTECT AOZ8804DI DFN-10 - --
U502 056G 662 21 ESD PROTECT AOZ8804DI DFN-10 - --
U506 056G 662 21 ESD PROTECT AOZ8804DI DFN-10 - --
U507 056G 662 21 ESD PROTECT AOZ8804DI DFN-10 - --
U601 356G0616048139 AUDIO TAS5721 15W TSSOP-48 - --
U702 356G0563417 LDO AP2125N-3.3TRG1 0.3A 3.3V SOT-23-3 - --
U703 356G0563008423 DC/DC SY8014FCC 4A ADJ SO-8E - --
U705 356GD563005123 DC/DC G5695T11U 1 6V SOT-23-5 - --
U706 356GD563008139 DC/DC G5759F11U 4A 5V SOP-8(FD) - --
U709 056G 563156 IC G9141T11U SOT23-5 - --
Q401 057G 763 79 FET AO4449 -7A/-30V SOIC-8 - --
Q402 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC - --
Q403 357G07630620HF HF MOSFET 2N7002K_R1_00001 0.3A 60V - --
Q404 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC - --
Q502 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23 - --
Q503 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23 - --
LC-32LD166
MAIN BOARD
INTEGRATED CIRCUITS
TRANSISTORS
MISCELLANEOUS PARTS
REF No. PARTS DESCRIPTION *
PRICE
CODE
Q504 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23 - --
Q506 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23 - --
Q601 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC - --
Q603 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC - --
Q701 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23 - --
Q702 057G 763 79 FET AO4449 -7A/-30V SOIC-8 - --
Q703 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23 - --
D401 093G 64S526SEM SWITCHING BAS316WS 250MA 100V SOD323 - --
D601 093G 64 42SEM SWITCHING BAV70 215MA 75V SOT-23 - --
D602 093G 64S526SEM SWITCHING BAS316WS 250MA 100V SOD323 - --
ZD101 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD102 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD103 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD104 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD105 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD106 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD107 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD108 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD109 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD110 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD111 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD112 093G 39GA28 T RLZ13B - --
ZD113 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD114 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD115 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD117 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD118 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD119 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD501 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD504 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD505 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD506 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD507 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD514 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD515 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD516 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD517 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
ZD518 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ - --
X101 093G 22S941 C CRYSTAL 7M41000001 41M 20PPM 12P - --
X401 393G022SA58TXC OSCILLATOR 7V24000026 24MHZ 12PF - --
TU101 394G0DVB00T31Y TUNER EUROPE SUT-RE231TN P AQ
L101 073G 6322910M CHIP INDUCTOR 2.2UH 10% 1.15R 15MA - --
L401 373G0806229CNM CHIP IND 2.2UH 30% 1.2A 0.15R MGFL2016F - --
L601 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L602 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L603 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L604 073G253S 81 M SMD CHOKE 10UH 20% 2.5A 0.047R 00036888 - --
L701 373G0806229CNM CHIP IND 2.2UH 30% 1.2A 0.15R MGFL2016F - --
L702 373G253S144DN0 SMD CHOKE 0.47UH 20% 20 0.0035R -- - --
L703 073G253S 88 M SMD CHOKE 15UH 20% 0.568R 2.8A - --
FB101 071G 56A221 M CHIP BEAD 0805 220R/2000MA - --
FB102 371G042P121M02 CHIP BEAD 0402 120R 25% MGLB1005M121T1R3 - --
FB105 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
FB106 071G 56A221 TA IND FXD 0805 EMI 100MHZ 220R R - --
FB401 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB403 071G 59C300 TA CHIP BEAD 0603 30R 25% FCM1608CF-300T06 - --
FB404 071G 56A221 TA IND FXD 0805 EMI 100MHZ 220R R - --
FB405 071G 59S121 M HIP BEAD 120R/500MA - --
DIODES
PACKAGED CIRCUITS
TUNER
COILS AND FILTERS
