LC-32LD164

LC-32LD165

LC-32LD166

REF No. PARTS DESCRIPTION

PRICE

CODE

C660 065G040268232KF CAP 0402 6.8NF 10% 50V X7R - --

C661 065G040268232KF CAP 0402 6.8NF 10% 50V X7R - --

C662 065G040210332KF CAP 0402 10NF 10% 50V X7R - --

C663 065G040210332KF CAP 0402 10NF 10% 50V X7R - --

C678 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --

C680 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C681 067G311R1013LT EC SMD 100UF 20% 16V 6.3*5.3 - --

C682 367G315M1013AV EC 100UF 20% --16V ---- -- --ERF1CM101 - --

C683 367G315M1013AV EC 100UF 20% --16V ---- -- --ERF1CM101 - --

C684 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --

C686 065G040222031JA CAP 0402 22PF J 50V NPO - --

C701 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C702 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C703 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --

C704 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --

C705 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C706 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --

C707 067G305M1013CV EC 100UF 20% 16V 6.3*7 - --

C709 065G060322515K A 0603 2.2UF K 16V X5R - --

C710 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --

C711 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C712 065G0805106A5K A CAP 0805 10UF 10% 10V X5R - --

C713 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C714 065G040233131JA MLCC 0402 330PF 50V NP0 +-5% - --

C715 065G080522605M T CAP 0805 22UF 20% 6.3V X5R JMK212 BJ226 - --

C716 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C717 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --

C718 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --

C719 067G305M1013CV EC 100UF 20% 16V 6.3*7 - --

C721 065G060322515K A 0603 2.2UF K 16V X5R - --

C722 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --

C730 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C731 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C732 065G120622615K T CAP CHIP 1206 22UF K 16V X5R - --

C733 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C735 065G040210412KY CAP 0402 100NF 10% 16V X7R - --

C736 065G040210425KY CAP 0402 100NF 10% 25V X5R - --

C737 065G120610622K T CAP 1206 10UF 10% 25V X7R - --

C738 065G040215232KY CAP CHIP 0402 1.5NF 50V X7R - --

R1001 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1002 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1003 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1004 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1005 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1006 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1007 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1008 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1009 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R101 061G0402000 JT RST 0402 0.05R MAX 1/16W - - --

R1010 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1011 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO - --

R1012 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1013 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1014 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1015 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1016 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1017 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1018 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1019 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R102 061G04021009FY RST CHIP 10R 1/16W 1% - --

R1020 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

R1021 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO - --

RESISTORS

REF No. PARTS DESCRIPTION

PRICE

CODE

R1022 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO -

R1023 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA -

R1024 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN -

R1025 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R1026 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA -

R1027 061G04022402FT RST 0402 24K 1% 1/16W TZAI YUAN -

R1028 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN -

R1029 061G0402510 JF RST CHIP 51R 1/16W 5% FENGHUA -

R103 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R1030 061G0402510 JF RST CHIP 51R 1/16W 5% FENGHUA -

R104 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R105 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R106 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R107 061G04027509FY RST CHIP 75R 1/16W 1% -

R108 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R1085 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA -

R1086 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA -

R1087 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R1088 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R109 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R110 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R1100 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1101 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1102 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1103 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1104 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1105 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1106 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1107 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1108 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1109 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R111 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN -

R1110 061G0402220 JY RST CHIPR 22 OHM +-5% 1/16W YAGEO -

R1111 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO -

R1112 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO -

R112 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R113 061G04027509FY RST CHIP 75R 1/16W 1% -

R114 061G04027509FY RST CHIP 75R 1/16W 1% -

R115 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R116 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R117 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R118 061G0402303 JY RST CHIP R 30KOHM 1/16W +/-5% YAGEO -

R119 061G0402303 JY RST CHIP R 30KOHM 1/16W +/-5% YAGEO -

R120 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R121 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R122 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R123 061G04022200DF RST CHIPR 220R +-0.5% 1/16W FENGHUA -

R124 061G04027509FY RST CHIP 75R 1/16W 1% -

R125 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R126 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R127 061G04027509FY RST CHIP 75R 1/16W 1% -

R128 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R129 061G04027509FY RST CHIP 75R 1/16W 1% -

R130 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R131 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R132 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R133 061G04027509FY RST CHIP 75R 1/16W 1% -

R134 061G0402513 JT RST CHIP 51K 1/16W 5% TZAI YUAN -

R135 061G04027509FY RST CHIP 75R 1/16W 1% -

R136 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN -

R137 061G0402000 JT RST 0402 0.05R MAX 1/16W - -

R138 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN -

R139 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN -
