Sharp LC-32LE280X Service Manual

[Reference values for adjustment reference]
Equipment : Luminance meter [Minolta CS-2000]
Level
Spec
Data
Adj. Spec.
Inspection
Spec.
Point
2 ref.
values
229
x= 0.2685
y= 0.2670
0.0010
0.0020
Point
1 ref.
values
40
x= 0.2685
y= 0.2670
0.0045
0.0090
Ref. : For Adjustment, set the LCD TV as below.
AV MODE : [DYNAMIC] (Reset)
Aging Time : Minimum 30 minutes
5. POWER CONSUMPTION
Power Consumption Measurement Method
1- Aging time : minimum 30 minutes (during offline)
2- Signal : Color Bar
3- Audio frequency : 400Hz
4- AV Mode : Dynamic
5- Picture Setting : Backlight/ Brightness/ Contrast : MAX, Active Contrast : OFF
6- ECO Setting : OFF
7- Audio Output (400Hz) : 1/8 of Maximum Audio Output (5W + 5W) ; VOL= 24
8- AC Input: 99VAC ~ 264VAC 50Hz
Power Consumption Specification TYPE LIMIT
Power Consumption (Mode : Dyanmic) 53 W +10% (at 240V)
 SUPER ECO (Mode ON) 25 W
Power Consumption at Stand-by Operating 0.56 W 0.6W
