45
YES
YES
The audio signal is not output
No audio signal output from SPDIF terminal (CN6202).
Is input source on HDMI? The SPDIF out not support HDMI
source.
No
Is the audio signal output from IC U2102 pin (92) (ASPDIF)
sent to CN6202?
No
Check IC U2102 and its peripheral circuits.
Change input source to others (AV, TV, etc.).
Check the line between IC U2102 and CN6202.
Terminal
To Next Page
