<External input Input(Component)>No picture on the display (7)
Does not the picture display when RCA cable plugged into component ?
Main UNIT:
Is Component Y/Pb/Pr signal sent to pin (2)/Y,
(4)/Pb, (6)/Pr of CN1202?
Is Component Y/Pb/Pr signal sent to pin (34)/Y1p,
(36)/Pb1p, (37)/Pr1p of IC U2102?
YES
Check the setting of an external input device that
connects of CN1202
NO
NO
Check the line between IC U2102 and CN1202.
Refer to “The picture doesn't appear in all modes.”
YES
Terminal
To Next Page
