LC-37D42U/LC-37D43U/LC-C3742U
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] LCD MODULE Assembly
1 R1LK370T3LZ5BW EZ N J LCD Module Ass'y
2 CANGTA274WJ01 AX N J Vessel (Top)
3 CANGTA277WJ01 AW N J Vessel (Bottom)
4 CANGTA275WJ01 AN N J Vessel (L, R), x2
5 CHLDZA701WJ01 BD N J Panel Holder Ass'y
6 CHLDZA711WJ01 AD N J Spacer Ass'y, x2
7 PSLDK2674TPNZ N J Reflection Sheet, x2
8 PSLDK2677TPNZ N J Diffusion Panel
9 CHLDZA704WJ01 N J Lamp Holder-L
10 CHLDZA703WJ01 N J Lamp Holder-R
11 CLMPCA003WJ01 N J Lamp Unit, x9
12 LHLDZA707WJKZ AF N J Lamp Holder (Bottom), x2
13 LHLDZA709WJKZ AC N J Sheet Holder, x6
14 LHLDZA713WJKZ AC N J Sheet Clip, x6
15 LHLDZA702WJKZ AC N J Lamp clip, x6
16 PREFL2378TPNZ N J Reflection Mirror
17 CCHSMA280WJ01 N J Chassis
18 PZETKA174WJKZ AL N J Insulation Sheet
19 RUNTKA216WJZZ BM N J INVERTER Unit A
20 RUNTKA217WJZZ BG N J INVERTER Unit B
21 PSLDMA892WJFW N J Shield Plate (for Inverter)
22 CPWBX3508TPZQ BR N J LCD CONTROL Unit
23 PSLDMA893WJFW AK N J Shield Plate (for LCD CONTROL Unit)
24 PSPAZB030WJKZ AB N J Spacer, x6
25 QPWBMD670WJNZ N J CS-FPC1, x2
26 LX-LZA101WJZZ AC N J Clip, x4
27 LX-BZ2102TPZZ N J Screw, x8
28 XEPS930P10000 AA J Screw, x10
29 XBPSN30P14000 AA J Screw, x12
30 XBPS730P06WS0 AA J Screw, x12
31 XBPS730P06000 AA J Screw, x4
