Sharp LC-37D90U

LC-37D90U
5 – 24
8 DZF O Zero Input Detect.
When the input data of DAC follow total 8192 LRCK cycles with “0” input data, this pin goes to “H”. And
when RSTN1 bit is “0”, PWDA bit is “0”, this pin goes to “H”.
9 CDTO O Control Data Output in Serial Mode and I2C pin= “L”.
10 LRCKB I/O Channel Clock B.
11 BICKB I/O Audio Serial Data Clock B.
12 SDTOB O Audio Serial Data Output B.
13 OLRCKA I/O Output Channel Clock A.
14 ILRCKA I/O Input Channel Clock A.
15 BICKA I/O Audio Serial Data Clock A.
16 SDTOA O Audio Serial Data Output A.
17 MCKO O Master Clock Output.
18 TVDD --- Output Buffer Power Supply, 2.7V~5.5V.
19 DVSS --- Digital Ground.
20 DVDD --- Digital Power Supply, 4.5V~5.5V.
21 XTI I X'tal Input.
22 XTO O X'tal Output.
23 TX O Transmit Channel Output.
When DIT bit= “0” , RX0~3 Through.
When DIT bit= “1” , Internal DIT Output.
24 MCLK2 I Master Clock Input
25 PDN I Power-Down Mode & Reset.
When “L”, the AK4683 is powered-down, all registers are reset. And then all digital output pins go “L”.
The AK4683 must be reset once upon power-up.
26 SDA I/O Control Data in Serial Mode and I2C pin= “H”.
27 SCL I Control Data Clock in Serial Mode and I2C pin= “H”.
28 CSN I Chip Select in Serial Mode and I2C pin= “L”.
29 SDTIA1 I Audio Serial Data Input A1.
30 SDTIA2 I Audio Serial Data Input A2.
31 SDTIA3 I Audio Serial Data Input A3.
32 SDTIB I Audio Serial Data Input B.
33 HVDD --- HP Power Supply, 4.5V~5.5V.
34 HVSS --- HP Ground.
35 HPR O HP Rch Output.
36 HPL O HP Lch Output.
37 MUTET --- HP Common Voltage Output.
38 LOUT2 O DAC2 Lch Positive Analog Output.
39 ROUT2 O DAC2 Rch Positive Analog Output.
40 LOUT1 O DAC1 Lch Positive Analog Output.
41 ROUT1 O DAC1 Rch Positive Analog Output.
42 VCOM --- DAC/ADC Common Voltage Output.
43 AVDD2 --- DAC Power Supply, 4.5V~5.5V.
44 AVSS2 --- DAC Ground.
45 LISEL O Lch Feedback Resistor Output.
46 LOPIN O Lch Feedback Resistor Input. 0.5 x AVDD1.
47 ROPIN O Rch Feedback Resistor Input. 0.5 x AVDD1.
48 RISEL O Rch Feedback Resistor Output.
49 AVSS1 --- ADC Ground.
50 AVDD1 --- ADC Power Supply, 4.5V~5.5V.
51 LIN1 I Lch Input 1.
52 RIN1 I Rch Input 1.
53 LIN2 I Lch Input 2.
54 RIN2 I Rch Input 2.
55 LIN3 I Lch Input 3.
56 RIN3 I Rch Input 3.
57 LIN4 I Lch Input 4.
58 RIN4 I Rch Input 4.
59 LIN5 I Lch Input 5.
60 RIN5 I Rch Input 5.
61 LIN6 I Lch Input 6.
62 RIN6 I Rch Input 6.
63 PVSS --- PLL Ground.
64 R --- External Resistor.
Pin No. Pin Name I/O Pin Function
