LC-37D90U
5 – 37
2.11. RH-iXB281WJ (ASSY: IC8101)
MPEG2 System Decoder LSI
• Block Diagram [RH-iXB281WJ (ASSY: IC8101)]
• Pin Function [RH-iXB281WJ (ASSY: IC8101)]
Pin No. Pin Name I/O Pin Function
AK1 SDAD12 O SDRAM address bus.
P3 SDAD11 O
R3 SDAD10 O
R4 SDAD9 O
T3 SDAD8 O
T4 SDAD7 O
U3 SDAD6 O
U4 SDAD5 O
V3 SDAD4 O
P2 SDAD3 O
P1 SDAD2 O
R2 SDAD1 O
R1 SDAD0 O
