LC-37D90U
5 – 40
G33 SBDAT15 I/O Data.
H33 SBDAT14 I/O
H32 SBDAT13 I/O
H31 SBDAT12 I/O
H30 SBDAT11 I/O
J30 SBDAT10 I/O
J31 SBDAT9 I/O
J32 SBDAT8 I/O
J33 SBDAT7 I/O
K33 SBDAT6 I/O
K32 SBDAT5 I/O
K31 SBDAT4 I/O
K30 SBDAT3 I/O
L30 SBDAT2 I/O
L31 SBDAT1 I/O
L32 SBDAT0 I/O
A31 SBWE_N O Data write enable.
L33 SBOE_M O Data output enable.
M33 SBCE7_N O Chip enable7.
M32 SBCE6_N O Chip enable6.
M31 SBCE5_N O Chip enable5.
M30 SBCE4_N O Chip enable4.
N30 SBCE3_N O Chip enable3.
N31 SBCE2_N O Chip enable2.
N32 SBCE1_N O Chip enable1.
N33 SBCE0_N O Chip enable0.
P32 SBBE1_N O Byte enable1.
P33 SBBE0_N O Byte enable0.
R30 SBACK_N O Bus acknowlege.
P30 SBCLK0 O Clock0 for Slow-Bus.
P31 SBCLK1 O Clock1 for Slow-Bus. 50MHz
B30 PCIAD31 I/O Address/Data multiplexed bus. (Not used: Pull-Down)
A30 PCIAD30 I/O
A29 PCIAD29 I/O
B29 PCIAD28 I/O
C29 PCIAD27 I/O
D29 PCIAD26 I/O
E28 PCIAD25 I/O
D28 PCIAD24 I/O
C28 PCIAD23 I/O
B28 PCIAD22 I/O
A28 PCIAD21 I/O
A27 PCIAD20 I/O
B27 PCIAD19 I/O
C27 PCIAD18 I/O
D27 PCIAD17 I/O
D26 PCIAD16 I/O
C26 PCIAD15 I/O
B26 PCIAD14 I/O
A26 PCIAD13 I/O
A25 PCIAD12 I/O
B25 PCIAD11 I/O
C25 PCIAD10 I/O
D24 PCIAD9 I/O
C24 PCIAD8 I/O
B24 PCIAD7 I/O
A24 PCIAD6 I/O
A23 PCIAD5 I/O
B23 PCIAD4 I/O
C23 PCIAD3 I/O
D22 PCIAD2 I/O
C22 PCIAD1 I/O
B22 PCIAD0 I/O
Pin No. Pin Name I/O Pin Function
