AL1 ACLSYC O Pin condition control.
Shared with UACTS3_N.
AK2 ACLSDI I Serial data input.
Shared with UARXD3.
AL2 ACLSDO O Serial data output.
Shared with UATXD3.
AK3 ACLBCLK I Bit clock.
Shared with UA3EXCLK.
AH5 TM0EXCLK I Timer0 clock.
Shared with and PIO26.
AJ4 TMOUT0 O Timer0 output.
Shared with and PIO27.
AJ5 TM1EXCLK I Timer1 clock.
Shared with and PIO28.
AK4 TMOUT1 O Timer1 output.
Shared with and PIO29.
AL3 TM2EXCLK I Timer2 clock.
For watch dog timer.
Shared with and PIO30.
AM2 TMCAP0 I Capture Timer0.
Shared with and PIO31.
AN2 TMCAP1 I Capture Timer1.
Shared with and PIO32.
AN10 PIO20 I/O 21bits Parallel I/O.
AM10 PIO19 I/O
AL10 PIO18 I/O
AK11 PIO17 I/O
AL11 PIO16 I/O
AM11 PIO15 I/O
AN11 PIO14 I/O
AN12 PIO13 I/O
AM12 PIO12 I/O
AL12 PIO11 I/O
AK12 PIO10 I/O
AK13 PIO9 I/O
AL13 PIO8 I/O
AM13 PIO7 I/O
AN13 PIO6 I/O
AN14 PIO5 I/O
AM14 PIO4 I/O
AL14 PIO3 I/O
AK14 PIO2 I/O
AK15 PIO1 I/O
AL15 PIO0 I/O
AN7 I2CDATA0 I/O I2C Serial data line0.
AL8 I2CCLK0 I/O I2C Serial clock0.
AM8 I2CDATA1 I/O I2C Serial data line1.
AK8 I2CCLK1 I/O I2C Serial clock1.
C3 USBCLK48M I USB clock 48MHz.
E5 USBDPLS I/O USB serial data plus.
D4 USBDMNS I/O USB serial data minus.
B2 USBOVCRNT I USB over current.
A2 USBPRTPOR O USB port power.
A8 TS0DATA7 I Transport stream port0 data input (Parallel).
B8 TS0DATA6 I
C8 TS0DATA5 I
D8 TS0DATA4 I
D9 TS0DATA3 I
C9 TS0DATA2 I
B9 TS0DATA1 I
A9 TS0DATA0 I
C10 TS0VALID I Transport stream port0 data valid.
B10 TS0SYNC I Transport stream port0 data sync.
D10 TS0ERROR I Transport stream port0 data error.
D11 TS0CLK I Transport stream port0 data clock.
