LC-37D90U
5 – 43
A5 TS1DATA7 I Transport stream port1 data input (Parallel).
B5 TS1DATA6 I
C5 TS1DATA5 I
E6 TS1DATA4 I
D6 TS1DATA3 I
C6 TS1DATA2 I
B6 TS1DATA1 I
A6 TS1DATA0 I
C7 TS1VALID I Transport stream port1 data valid.
B7 TS1SYNC I Transport stream port1 data sync.
A7 TS1ERROR I Transport stream port1 data error.
D7 TS1CLK I Transport stream port1 data clock.
B3 TS2DATA I Transport stream port2 data input (Serial).
C4 TS2VALID I Transport stream port2 data valid.
B4 TS2SYNC I Transport stream port2 data sync.
A3 TS2ERROR I Transport stream port2 data error.
D5 TS2CLK I Transport stream port2 data clock.
A10 TSREQ0 O Transport stream data input request0.
A4 TSREQ1 O Transport stream data input request1.
D13 TSOUTDATA7 O Transport stream DATA7. Shared with DBUGPCST7.
C13 TSOUTDATA6 O Transport stream DATA6. Shared with DBUGPCST6.
B13 TSOUTDATA5 O Transport stream DATA5. Shared with DBUGPCST5.
A13 TSOUTDATA4 O Transport stream DATA4. Shared with DBUGPCST4.
A12 TSOUTDATA3 O Transport stream DATA3. Shared with DBUGPCST3.
B12 TSOUTDATA2 O Transport stream DATA2. Shared with DBUGPCST2.
C12 TSOUTDATA1 O Transport stream DATA1. Shared with DBUGPCST1.
D12 TSOUTDATA0 O Transport stream DATA0. Shared with DBUGPCST0.
D14 TSOUTCLKI I Output transport stream data clock input Shared with DBUGTCK.
C14 TSOUTCLKO O Transport stream data clock output. Shared with DBUGDCLK.
C11 TSOUTVALID O Transport stream data clock valid. Shared with DBUGPCST8.
B11 TSOUTCGMS O Transport stream CGMS (Copy Control), TSCH (Device Number) serial data output.
A11 TSOUTSYNC O Transport stream data sync.
R33 ASDO4 O Audio data serial output4.
R32 ASDO3 O Audio data serial output3. Shared with DBUGTPC3.
R31 ASDO2 O Audio data serial output2. Shared with DBUGTPC2.
T31 ASDO1 O Audio data serial output1. Shared with DBUGTPC1.
T32 ASDO0 O Audio data serial output0. Shared with DBUGTDO.
T30 AMCLK I Audio oner sampling clock 256fs or 384fs.
T33 ALRCKO O Left/Right clock for audio output.
U33 ABCKO O Bit clock for audio output.
V31 ASDI1 I Audio data serial input1. Shared with DBUGTDI.
V32 ASDI0 I Audio data serial input0. Shared with DBUGTMS.
U30 ALRCKI I Left/Right clock for audio input. Shared with DBUGTRST_N.
V30 ABCKI I Bit clock for audio input.
V33 CMPREQ_N I PES request signal for external AAC decoder.
U32 CMPDAT O PES data output.
U31 CMPCLK O PES data bits clock output.
AJ28 VIDINCLK I External video input clock. Shared with DBUGTCK.
AH29 VIDINH I External video horizontal sync. Shared with DBUGDCLK.
AJ29 VIDINV I External video vertical sync. Shared with DBUGPCST8.
AK29 VIDINDATA7 I External video data input7. Shared with DBUGPCST7 and VCRDOUT7.
AL29 VIDINDATA6 I External video data input6. Shared with DBUGPCST6 and VCRDOUT6.
AM29 VIDINDATA5 I External video data input5. Shared with DBUGPCST5 and VCRDOUT5.
AN29 VIDINDATA4 I External video data input4. Shared with DBUGPCST4 and VCRDOUT4.
AN30 VIDINDATA3 I External video data input3. Shared with DBUGPCST3 and VCRDOUT3.
AM30 VIDINDATA2 I External video data input2. Shared with DBUGPCST2 and VCRDOUT2.
AL30 VIDINDATA1 I External video data input1. Shared with DBUGPCST1 and VCRDOUT1.
AK30 VIDINDATA0 I External video data input0. Shared with DBUGPCST0 and VCRDOUT0.
AJ30 VIDINCBCR7 I External video data CB/CR input7. Shared with DBUGTDO.
AK31 VIDINCBCR6 I External video data CB/CR input6. Shared with DBUGTDI.
AL31 VIDINCBCR5 I External video data CB/CR input5. Shared with DBUGTMS.
AM31 VIDINCBCR4 I External video data CB/CR input4. Shared with DBUGTRST_N.
AN31 VIDINCBCR3 I External video data CB/CR input3. Shared with DBUGTPC3.
AN32 VIDINCBCR2 I External video data CB/CR input2. Shared with DBUGTPC2.
Pin No. Pin Name I/O Pin Function
