LC-37D90U
5 – 46
E8, AA6, AC6, AE6,
AG28, AG29, AG5,
AG6, AH10, AH12,
AH14, AH16, AH19,
AH21, AH23, AH25,
AH27, AH7, AJ8,
E20, E24, E27,
F10, F12, F14, F16,
F19, F21, F23, F25,
F28, F5, F6, F7,
G29, H28, H6, K28,
K6, M28, M6, P28,
P6, T28, T6, V28,
W6, Y28
VSS1 --- VSS for output buffer: 0V.
AB5, AC28, AD28,
AD5, AJ11, AJ13,
AJ15, AJ17, AJ18,
AJ20, AJ22, AJ24,
AJ26, AJ7, D18,
D19, D21, D23,
D25, E11, E13,
E15, E17, E7, G5,
J29, L29, L5, N29,
N5, R29, R5, U29,
U5, V5, W29, Y5
VSS2 --- VSS for input buffer and digital part: 0V.
Pin No. Pin Name I/O Pin Function
