LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 20
11.Remove the 5 lock screws and detach the Stand Angle Sub Ass’y.
12.Remove the 4 lock screws and detach the Stand Support Angle.
14
37 LCD PANEL
STAND ANGLE SUB ASSY
14
15
15
15
Back side
STAND SPPRT ANG
STAND ANG
