English - 24 -
Screw Dimensions Wall Mounting
Screw length = A+B
Screw
Cabinet
Wall mount angle
MODEL VESA
TO THE PRODUCT
MIN. / MAX. SCREW LENGTH
(A LENGTH)
LC-32LD145E
LC-32LD145K
LC-32LD145V
200 x 100 (W x H) M4 X 6 / M4 X 10
LC-39LD145E
LC-39LD145K
LC-39LD145V
200 x 200 (W x H) M6 X 10 / M6 X 14
