Sharp LC-39LE440U User Manual

34
YES
YES
YES
No sound from external input devices (3)
Does not the sound of the audio signal input to USB go out?
YES
NO
Is USB stick audio format correct? Change to correct mp3 format
MAIN
Is the USB +5V Q7105 sent to pin (1) of CN1104?
Is the USB con (CN1104) signal properly sent to
pin (233) (USB_DM0) and pin (234) (USB DP0) of
IC U2102?
Refer to “No sound output in all modes”.
NO
NO
Check the connection to Q7105 and the external
input device.
Check the line between CN1104 and IC2102

Sharp LC-39LE440U Specifications

General

Display diagonal	39 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	88 °
3D	No
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	-
HDMI ports quantity	3
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black
AC input voltage	120 V
Power consumption (standby)	1 W

Weight and Dimensions

Depth (with stand)	229.9 mm
Height (with stand)	611.6 mm
Weight (with stand)	18510 g
Depth (without stand)	44.96 mm
Width (without stand)	916.4 mm
Height (without stand)	577.8 mm
Weight (without stand)	16010 g
