Sharp LC-39LE440U User Manual

35
.
YES
The audio signal is not output
No audio signal output from Headphone terminal (CN6201).
Is audio signal output from pin (12) (OUTL) and pin
(3) (OUTR) of IC U6201 to Jack (CN6201)?
Terminal
Check IC U2102 and its peripheral circuits.
Is the audio signal output from IC U2102 pin (74)
(AL1O) and pin (76) (AR1O) to pin (3) (OUTR) and
pin (12) (OUTL) of IC U6201
Check the connection to HPOL(R) OUT and
external devices.
Check the line between IC U2102 and IC U6201.
YES
No
No

Sharp LC-39LE440U Specifications

General

Display diagonal	39 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	88 °
3D	No
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	-
HDMI ports quantity	3
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black
AC input voltage	120 V
Power consumption (standby)	1 W

Weight and Dimensions

Depth (with stand)	229.9 mm
Height (with stand)	611.6 mm
Weight (with stand)	18510 g
Depth (without stand)	44.96 mm
Width (without stand)	916.4 mm
Height (without stand)	577.8 mm
Weight (without stand)	16010 g
