<External input Input(Rear HDMI3)>No picture on the display (5)
Does not the picture display when HDMI cable plugged into HDMI 3?
Terminal
Is TMDS signal input into pin
RX2_2/ RX2_2B,
RX2_1 / RX2_1B,
RX2_0/ RX2_0B
RX2_C/ RX2_CB of IC U2102?
Refer to “The picture doesn't appear in
all modes.”?
Check the line between pin (1) of IC
U2102 and CN8102.
Check the line between IC U2102 and
NO
NO
YES
YES
Is the HOT_PLUG detection function of
pin (19) of a HDMI terminal (CN8102)
normal?
<External
Check the connection and setup with
the external HDMI devices.

Sharp LC-39LE440U Specifications

General

Display diagonal	39 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	88 °
3D	No
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	-
HDMI ports quantity	3
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black
AC input voltage	120 V
Power consumption (standby)	1 W

Weight and Dimensions

Depth (with stand)	229.9 mm
Height (with stand)	611.6 mm
Weight (with stand)	18510 g
Depth (without stand)	44.96 mm
Width (without stand)	916.4 mm
Height (without stand)	577.8 mm
Weight (without stand)	16010 g
