Sharp LC-39LE440U User Manual

42
<External input USB>No picture on the display (6)
Does not the picture display when USB cable plugged into USB port?
Main UNIT:
Is USB stick video format correct?
Is the USB +5V sent to pin (1) of
YES
Change to correct .jpg or .jpeg or .png or
.bmp format.
NO
NO
Check the fuse F1101 and the external
input device.
Is the USB con (CN1104) signal properly
sent to pin (233) (USB_DM0) and pin
(234) (USB_DP0) of IC U2102?
YES
Refer to “The picture doesn't appear in
NO
Check the line between CN1104 and IC
YES

Sharp LC-39LE440U Specifications

General

Display diagonal	39 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	88 °
3D	No
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	-
HDMI ports quantity	3
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black
AC input voltage	120 V
Power consumption (standby)	1 W

Weight and Dimensions

Depth (with stand)	229.9 mm
Height (with stand)	611.6 mm
Weight (with stand)	18510 g
Depth (without stand)	44.96 mm
Width (without stand)	916.4 mm
Height (without stand)	577.8 mm
Weight (without stand)	16010 g
