Sharp LC-39LE650E Service Manual

130
LC-39/50LE650
LC-39/50LE651
LC-39/50LE652
REF No. PARTS
DESCRIPTION
*
PRICE
CODE
J 2702 QJAKEA125WJZZ RCA JACK FEMALE PCB SIDE ENTRY ORANGE(YU
J 9501 QJAKZA131WJQZQ RJ45 JACK SIDE PCB 8P8C MTJ-882BX1-FS-EU
J 9551 QSOCZA276WJQZ SOCKET USB DOUBLE UAR64
J 9552 QSOCZA205WJQZ SOCKET UAR27-4K5C0L
P 2705 QPLGNA160WJZZY CONECTOR SM04B-PASS-TBT(LF)
P 3800 QPLGNA331WJZZY CONNECTOR SM11B-GHS-TB (LF)(SN), (JST)
P 9601 QPLGNB224WJZZY CONNECTOR A2010WR0-14PS-SHP (JWT)
SC 0501 QSOCNA816WJZZ VGA IN 15P. CONN VERTICAL (ACON)
SC 0552 QSOCZA161WJZZ SCART RGB-11H
SC 1501 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E
SC 1502 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E
SC 1503 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E
SC 1504 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E
SC 2601 QCNCWB127WJZZY CONE LVDS 51P. I-PEX 20555-051E EVAFLEX5
SC 2603 QCNCWB128WJZZY CONC LVDS 41P. I-PEX 20555-041E EVAFLEX5
SC 4401 QCNCMA386WJSA PCMCIA CONN.LONG TYPE 68P 5V(CONCRAFT-TO
PSLDMB855WJFW MS SHIELD CASE WITH CON. 2.GD30T19X10X14
PSLDMB856WJFW MS SHIELD CASE COVER (2.D30T19X10X14)
QPWBXG135WJN1 PWB MAIN UNIT LE65x/LE75x Version N1
IC 0503 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 0540 VHINC7SZ04P-1Y IC INVERTER GATE NC7SZ04P5X (FAIRCHILD)
IC 0552 RH-IXD540WJZZY IC VIDEO AMPLIFIER +6dB BH76206HFV(ROHM)
IC 1103 RH-IXD523WJZZQ IC Si2167-B20-GM SiLABS DVB-T/C/S/S2 DEM
IC 1104 VHIS132B50M-1Y IC S-1132B50-M5T1G LDO 5V (SEIKO)
IC 1106 RH-IXD518WJZZY IC Si2178-A20-GMR SiLABS, SILICON TUNER
IC 1301 RH-IXD310WJZZY IC LNBH23QTR(QFN32 5x5mm) ST
IC 1505 VHIBU16028V-1Q IC 3TO1 HDMI SWITCH BU16028KV-ZAE (ROHM)
IC 1506 VHITC7SH08U-1Y IC 2-INPUT AND GATE TC7SH08-FU (TOSHIBA)
IC 1507 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1508 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1509 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1510 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1511 VHIESD7004M-1Y Suppresor HDMI Array, ESD7004MUTAG (ON S
IC 1512 VHIESD7004M-1Y Suppresor HDMI Array, ESD7004MUTAG (ON S
IC 2701 VHISTA333BW-1L IC 40W AUDO AMPL. 2.1 STA333BM(ST MICRO)
IC 2702 RH-IXD542WJZZY IC TS488IQT POPFree HeadPhones Ampl (ST
IC 3301 RH-IXD514WJZZQ IC FLI7560-AAB CUT1.1 STMICRO FREEMAN PR
IC 3302 VHIS80927NM-1Y CI S-80927CNMC-G8XT2G
IC 3303 VHIBR24T64J-1Y IC NVM 64Kb BR24T64FJ-WE2 (ROHM)
IC 3501 RH-IXD538WJZZQ ICDDR3-1600 MT41J128M16JT-125:K(MICRON)
IC 3502 RH-IXD538WJZZQ ICDDR3-1600 MT41J128M16JT-125:K(MICRON)
IC 3503 RH-IXD538WJZZQ ICDDR3-1600 MT41J128M16JT-125:K(MICRON)
IC 3800 RH-IXD550WJZZY IC CPU STM8S105K4T6CTR (ST MICRO)
IC 4401 VHILCX245FT-1Y CI TC74LCX245FT(EL,K)
IC 4402 VHILCX244FT-1Y CI TC74LCX244FT(EL,K)
IC 4403 VHIS170B50U-1Y CI S-1170B50UC-0UJTFG
IC 4404 VHILCX244FT-1Y CI TC74LCX244FT(EL,K)
IC 8401 RH-IXD551WJQZQ IC NANDFLASH 2Gb MT29F2G08ABAEAWP:E(MICR
IC 9501 RH-IXD543WJZZY IC ETH-PHY RMII, KSZ8081RNDCATR (MICREL)
IC 9551 RH-IXD187WJZZY CI AAT4614IGU-2-T1 ANALOGIC TECH
DUNTKG135WE07
LE652 MAIN Unit
INTEGRATED CIRCUITS
REF No. PARTS
DESCRIPTION
*
PRICE
CODE
IC 9552 VHI2514BAEZ-1Q IC USB2514B-AEZG
IC 9553 VHIS170B50U-1Y CI S-1170B50UC-0UJTFG
IC 9601 VHIBD9328EF-1Y IC BD9328EFJ 2A DCDC ROHM
IC 9602 RH-IXD534WJZZY IC BD95841MUV-E2 (Rohm)
IC 9603 VHIS170B25U-1Y IC S-1170B25UC LDO 2.5V (SEIKO)
IC 9605 VHIS132B50M-1Y IC S-1132B50-M5T1G LDO 5V (SEIKO)
IC 9606 RH-IXD533WJZZY IC BD80GA3WEFJ LDO (Rohm)
IC 9608 RH-IXD532WJZZY IC BU33TD3WG LDO (Rohm)
IC 9701 VHIBD9328EF-1Y IC BD9328EFJ 2A DCDC ROHM
Q 1101 VSMMBT2907A-1Y TRT MMBT2907ALT1G
Q 1501 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI
Q 1502 VSRT1N441U/-1Y TRT RT1N441U-T111-1
Q 1505 VS2N7002KA+-1Y TRT 2N7002KA-RTK/P (KEC)
Q 2602 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI
Q 2604 RH-TXA064WJZZY TRT AO3415 P-Channel Mosfet ALPHA & OMEG
D 0501 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0502 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0503 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0504 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0511 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0529 VHDDAN202K/-1Y DIODO DAN202KT146
D 0540 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0556 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0559 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0560 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0561 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0562 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1102 VHEVBUS05L1-1Y ESD DIODE VBUS05L1-DD1-G-08 VISHAY
D 1301 VHDRB156L40-1Y DIODO RB156L-40TE25
D 1302 VHDRB156L40-1Y DIODO RB156L-40TE25
D 1303 VHDD1F60///-1Y DIODO D1F60-5053
D 1304 VHDRB156L40-1Y DIODO RB156L-40TE25
D 1305 VHDRB156L40-1Y DIODO RB156L-40TE25
D 1501 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1502 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1503 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1504 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1505 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1506 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1507 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1508 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1509 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1511 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1513 VHDDAN202K/-1Y DIODO DAN202KT146
D 1514 VHDDAN202K/-1Y DIODO DAN202KT146
D 1515 VHDDAN202K/-1Y DIODO DAN202KT146
D 1516 VHDDAN202K/-1Y DIODO DAN202KT146
D 2707 VHDHSU119//-1Y DIODO HSU119TRF
D 2708 VHDHSU119//-1Y DIODO HSU119TRF
D 3301 VHDRB520S30-1Y DIODO RB520S-30
D 3805 VHDHSU119//-1Y DIODO HSU119TRF
TRANSISTORS
DIODES
