LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
6 – 6
Trouble Shooting Panel Module
When C-S FPC (4pieces (for LE835) or 2pieces (for LE830/831/832) is replaced, does screen display normally?
NO
YES
Replace C-S FPC (4pieces (for LE835) or 2pieces(for LE830/831/832).
When C-PWB is replaced, does screen display normally?
NO
YES
Replace C-PWB.
(Adjust “VCOM ADJ” after replace C-PWB)
Replace Panel HIRAKI.
(Adjust “VCOM ADJ” after replace Panel HIRAKI)
