LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
6 – 8
No video (2)
COMPONENT: No external input video [INPUT-5]
Is INPUT-5 selected on the input select menu screen?
Is the INPUT-SELECT for the input signal?
YES
NO
Select INPUT-5 on the input select menu screen for the
right input signal.
Does the COMP1_PLUG detection function?
Check the line between pin (17) of input terminal (J510)
and pin (L32) of IC3303 (CPU).
In LE835U.
Are the LVDS signal input to the pin of P2601?
LVDS0_FPGA_D0P/N (39/40pin), LVDS0_FPGA_D1P/N (37/38pin),
LVDS0_FPGA_D2P/N (35/36pin), LVDS0_FPGA_D3P/N (30/31pin),
LVDS0_FPGA_D4P/N (28/29pin), LVDS0_FPGA_CLKP/N_74MHz (32/33pin),
LVDS1_FPGA_D0P/N (25/26pin), LVDS1_FPGA_D1P/N (23/24pin),
LVDS1_FPGA_D2P/N (21/22pin), LVDS1_FPGA_D3P/N (16/17pin),
LVDS1_FPGA_D4P/N (14/15pin), LVDS1_FPGA_CLKP/N_74MHz (18/19pin).
NO Check IC3303 and its peripheral circuits.
(IC3501/IC3502, etc)
In LE830U/LE831U/LE832U.
Is the T-CON PWB connected?
VBO_HTPDN (40pin), VBO_LOCKN (39pin) of P2604 become Low if there is no
problem in the connection.
NO Check the panel module and harness.
YES
Are the V-By-One signal input to the pin of P2604?
VBO_CN_TXA+/- (36/37pin), VBO_CN_TXB+/- (32/33pin),
VBO_CN_TXC+/- (28/29pin), VBO_CN_TXD+/- (24/25pin).
NO Check IC3303 and its peripheral circuits.
(IC3501/IC3502/IC3503, etc)
YES
Check the panel module and harness.
To Next Page
