Sharp LC-40LE832U

LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
2 – 1
LC-40LE830U
Service Manual
CHAPTER 2. OPERATION MANUAL
[1] Parts Name
TV (Front)
3D infrared emitter *1
3D Model Only
Center Icon illumination
POWER *3INPUT
VOL /
MENU
Remote control sensor
OPC sensor *2
CH /
*1 This panel emits the infrared signal towards the 3D Glasses you wear when you view 3D images.
Do not place anything between the 3D infrared emitter on the TV and the infrared receiver on the
3D Glasses. (3D Model: LC-40/46/52/60LE835U Only)
*2 OPC: Optical Picture Control.
*3 for using the touch sensor panel.
TV (Rear)
RS-232C terminal
Antenna/
Cable in
COMPONENT
terminals
DIGITAL AUDIO
OUTPUT terminal
HDMI 3 terminal
HDMI 4 terminal
HDMI 1 terminal
ARC: Audio Return Channel
VIDEO 2 terminals
VIDEO 1 terminals
AUDIO OUT terminal
USB 1 terminal
USB 2
terminal
ETHERNET
terminal
HDMI 2 terminal
PC IN terminal
*1
*1
*1
AUDIO IN terminal
(shared for PC IN
andHDMI1)*2
*1 for external equipment connection.
*2 for details on the Audio Select function.
