Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
110
D9802 393G0060A13 RECTIFIER STTH10LCD06FP 600V TO-220FPAC
D9105 093G 60258 DIODE FME-220B TO-220 SANKEN
D9105 093G 60946 SCHOTTKY MBRF20150CT C0 20 150 ITO-220AB
D9803 093G 60S 15 T SCHOTTKY RB160M 60 TR 1A 60V SOD-123
D9103 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D8109 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D8108 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D8107 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D8100 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D9803 393G060S50000T00HF HF SS1060FL_R1_00001 1A 60V SOD123FL
D8109 393G064SA0500T SWITCHING L1N4148WT1G 0.15A 75V SOD-123
D8108 393G064SA0500T SWITCHING L1N4148WT1G 0.15A 75V SOD-123
D8107 393G064SA0500T SWITCHING L1N4148WT1G 0.15A 75V SOD-123
D9103 393G064SA0500T SWITCHING L1N4148WT1G 0.15A 75V SOD-123
D8100 393G064SA0500T SWITCHING L1N4148WT1G 0.15A 75V SOD-123
D8101 093G 6026T52T CTIFIER DIODE FR107
D9102 093G 6026T52T CTIFIER DIODE FR107
D9104 093G 60953 SCHOTTKY FR107G-A0 1A 1000V DO-41
D9102 093G1080 252T RECTIFIER SARS01-V1 1.2A 800V DO-41
D8101 093G1080 252T RECTIFIER SARS01-V1 1.2A 800V DO-41
D9104 393G0060A1052T RECTIFIER FR107G 1A 1000V DO-41
ZD9801 393G039S95400T00HF ZENER BZT52-B3V6_R1_00001 3.6V 0.41W SOD
ZD8105 393G039SA1200T ZENER BZT52-B22 22V 0.41W SOD-123 150C
ZD8106 393G039SA1200T ZENER BZT52-B22 22V 0.41W SOD-123 150C
ZD8104 393G039SA1200T ZENER BZT52-B22 22V 0.41W SOD-123 150C
ZD9401 393G039SA1400T ZENER BZT52-B16_R1_00001 16V 0.41W
ZD9803 393G039SA1400T ZENER BZT52-B16_R1_00001 16V 0.41W
ZD9802 393G039SA1400T ZENER BZT52-B16_R1_00001 16V 0.41W
ZD9101 393G039SA1500T ZENER BZT52-B30 30V 0.41W SOD-123
ZD9102 393G039SA1500T ZENER BZT52-B30 30V 0.41W SOD-123
ZD9106 393G039SA1500T ZENER BZT52-B30 30V 0.41W SOD-123
ZD8103 393G039SA1500T ZENER BZT52-B30 30V 0.41W SOD-123
COIL&FILTER
F9901 384G005600506C FUSE 5A 250V MST 5A 250V(H)
FB9902 371G0055021H02 BEAD 6.5*12.5 700R 25% BF-I60100R-815
FB9901 371G0055021H02 BEAD 6.5*12.5 700R 25% BF-I60100R-815
FB9905 371G0055021H02 BEAD 6.5*12.5 700R 25% BF-I60100R-815
FB9903 371G0055021H02 BEAD 6.5*12.5 700R 25% BF-I60100R-815
FB9803 095G 90 23 JUMP WIRE - -
FB9103 095G 90 23 JUMP WIRE - -
FB9805 071G 55 26 H BEAD 3.5*6.0*0.8 127R 25% BF-I35060R-796
FB9805 071G 55 26 S BEAD 3.5*6 127R 25% LB3.5*0.8*6-2
FB9802 071G 55 29 HF FERRITE BEAD 3.5*2.2*0.8 TAPING HF
FB9101 071G 55 29 HF FERRITE BEAD 3.5*2.2*0.8 TAPING HF
J9909 095G 90 23 JUMP WIRE - -
J9933 095G 90 23 JUMP WIRE - -
J9934 095G 90 23 JUMP WIRE - -
J9911 095G 90 23 JUMP WIRE - -
J9925 095G 90 23 JUMP WIRE - -
J9922 095G 90 23 JUMP WIRE - -
J9906 095G 90 23 JUMP WIRE - -
J9902 095G 90 23 JUMP WIRE - -
J9907 095G 90 23 JUMP WIRE - -
J9930 095G 90 23 JUMP WIRE - -
