32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U

111

J9918 095G 90 23 JUMP WIRE - -

J9921 095G 90 23 JUMP WIRE - -

J9910 095G 90 23 JUMP WIRE - -

J9916 095G 90 23 JUMP WIRE - -

J9931 095G 90 23 JUMP WIRE - -

J9919 095G 90 23 JUMP WIRE - -

J9917 095G 90 23 JUMP WIRE - -

J9908 095G 90 23 JUMP WIRE - -

J9913 095G 90 23 JUMP WIRE - -

J9915 095G 90 23 JUMP WIRE - -

J9903 095G 90 23 JUMP WIRE - -

J9926 095G 90 23 JUMP WIRE - -

J9904 095G 90 23 JUMP WIRE - -

J9905 095G 90 23 JUMP WIRE - -

J9924 095G 90 23 JUMP WIRE - -

J9912 095G 90 23 JUMP WIRE - -

J9939 095G 90 23 JUMP WIRE - -

J9927 095G 90 23 JUMP WIRE - -

J9929 095G 90 23 JUMP WIRE - -

J9914 095G 90 23 JUMP WIRE - -

J9920 095G 90 23 JUMP WIRE - -

L9801 373G0174312CP0 PFC CHOKE 240UH 8% 1.5A -

L9801 373G0174312X00 PFC CHOKE 240UH 8% 1.5A -

L9902 373G0174314L00 LINE FILTER 12MH MIN 1.5 -

L9901 373G0174314L00 LINE FILTER 12MH MIN 1.5 -

L9901 373G0174314X00 LINE FILTER 12MH MIN 1.5A 3LFT18106-123

L9902 373G0174314X00 LINE FILTER 12MH MIN 1.5A 3LFT18106-123

L9101 373G0253247H00 CHOKE COIL 3UH 15% DR8*8 5A

L8100 373G0253247H00 CHOKE COIL 3UH 15% DR8*8 5A

L9100 373G0253247H00 CHOKE COIL 3UH 15% DR8*8 5A

L9101 373G0253247X00 CHOKE COIL 3UH 15% DR8*8 5A

L8100 373G0253247X00 CHOKE COIL 3UH 15% DR8*8 5A

L9100 373G0253247X00 CHOKE COIL 3UH 15% DR8*8 5A

TRANSISTOR

Q8100 357G0667650006 MOSFET TK11A65D 11A 650V TO-220SIS

Q9801 057G 667954 MOSFET TK18A60V 18A 600V SC-67

Q9100 057G 667931 MOSFET AOTF8N65 8A 650V TO-220FP

Q8102 057G 417517 TRA LMBT3906LT1G -200MA/-40V SOT-23 LRC

Q9402 057G 417526 SMALLTRAN MMBT3906 -0.2A -40V SOT-23

Q9401 357G0761A0100T SMALLTRAN BTC4672M3 5A 50V 0.6W SOT-89

Q8103 357G07630620HF HF MOSFET 2N7002K_R1_00001 0.3A 60V

Q9403 357G07630620HF HF MOSFET 2N7002K_R1_00001 0.3A 60V

Q9106 357G07630620HF HF MOSFET 2N7002K_R1_00001 0.3A 60V

RESISTOR

R9808 061G3SWJ70759B SY RST WD 0.07R 5% 3W

R9808 361G3SWJ70759B00TZ RST WD 0.07R 5% 3W NKNP3WS0R07JMS10

R9128 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA

R9128 061G0805000 JT RST 0805 0.05R MAX 1/8W

R8156 061G0805000 JT RST 0805 0.05R MAX 1/8W

R8101 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA

R9104 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA

R9104 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN

R8101 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN

R9121 061G08051001FF RST CHIPR 1KOHM +-1% 1/8W FENGHUA
