Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
94
C8110 065G080510231J M CAP 0805 1NF 5% 50V NP0
C8114 065G080510332K Y CAP CHIP 0805 10N 50V X7R +/-10%
C8108 065G080510432K Y CAP CHIP 0805 100N 50V X7R +/-10%
C9111 065G080510432K Y CAP CHIP 0805 100N 50V X7R +/-10%
C8122 065G080510432K Y CAP CHIP 0805 100N 50V X7R +/-10%
C8123 065G080510532K M CAP 0805 1UF 10% 50V X7R
C8121 065G080510532K M CAP 0805 1UF 10% 50V X7R
C9108 065G080522131J Y CAP CHIP 0805 220P 50V NP0 +/-5%
C9109 065G080522232K Y CAP CHIP 0805 2N2 50V X7R +/-10%
C9201 065G080522432K M CAP 0805 220NF 10% 50V X7R GRM21BR71H224
C9159 065G080522432K M CAP 0805 220NF 10% 50V X7R GRM21BR71H224
C9172 065G080522432K M CAP 0805 220NF 10% 50V X7R GRM21BR71H224
C8104 065G080522522K T CAP 0805 2.2UF 10% 25V X7R
C8119 065G080522522K T CAP 0805 2.2UF 10% 25V X7R
C9157 065G080522522K T CAP 0805 2.2UF 10% 25V X7R
C9161 065G1206102B2K M CAP 1206 1NF 10% 630V X7R GRM31BR72J102
C8113 367G515L151HNT EC 150UF 20% 50V 10X12.5 9000 HR 1280MA
C8112 367G515L151HNT EC 150UF 20% 50V 10X12.5 9000 HR 1280MA
C9153 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C9158 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C9154 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C9155 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C9151 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C8101 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C9152 367G515L471FNT000A EC 470UF 20% 25V 10X12.5 9000 HR 1.7A E
C9112 367G515X229HNB EC 2.2UF 20% 50V 5X11 5000 HR 43MA EKY-
C9105 065G 1K22293S CAP CER 2.2NF 10% 1KV R TAPING
C9905 065G306K2212MR CAP Y1 220PF 10% 250V Y5P DE1B3KX221KREA
C9906 065G306K2212MR CAP Y1 220PF 10% 250V Y5P DE1B3KX221KREA
C9910 065G306K4712MR CAP Y1 470PF 10% 250V Y5P DE1B3KX471KRE
C9909 065G306K4712MR CAP Y1 470PF 10% 250V Y5P DE1B3KX471KRE
C9107 067G 2152207NT KY50VB22M-TP5 5*11
C8102 365G001J1006ST CAP CER 10PF 5% 1KV 8SL100J102N56G
C9119 365G001J4706ST CAP CER 47PF 5% 1KV SL 8SL470J102N56G
C9904 365G306K1012MR CAP Y1 100PF 10% 250V Y5P DE1B3KX101KRE
C9903 365G306K1012MR CAP Y1 100PF 10% 250V Y5P DE1B3KX101KRE
DIODE
BD901 393G0050460A12 BRIDGE D10JBB80V 10A 800V KBJ
D8104 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
D8101 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
D9151 093G 60987 SCHOTTKY FMEN-2308 30A 80V TO-22OF
D9152 093G 60987 SCHOTTKY FMEN-2308 30A 80V TO-22OF
D9157 093G3004 2 HF SR34H PAN JIT
D8103 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D9111 393G006432S0HF SWITCHING 1N4148W 0.15A 75V SOD-123
D9102 393G060S93400T00HF HF SS0520_R1_00001 0.5A 20V SOD-123
D9103 093G 60953 SCHOTTKY FR107G-A0 1A 1000V DO-41
D9101 093G 60953 SCHOTTKY FR107G-A0 1A 1000V DO-41
ZD9101 393G039SA2800T ZENER BZT52-B36 36V -- --
ZD9102 393G039SA2800T ZENER BZT52-B36 36V -- --
ZD9152 393G039SA2900T ZENER BZT52-B15 15V 0.41 SOD-123
COIL&FILTER
F9901 384G005600506L FUSE 5A 250V MST 5A 250V(H)
F9902 384G005600506L FUSE 5A 250V MST 5A 250V(H)
