32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U

FB9907 071G 55906 H BEAD 6.0*9.2 510R MIN BF-I60090C-794

FB9906 071G 55906 H BEAD 6.0*9.2 510R MIN BF-I60090C-794

FB9902 071G 55 26 H BEAD 3.5*6.0*0.8 127R 25% BF-I35060R-796

FB9905 071G 55 29 FERRITE BEAD

FB9910 071G 55 29 FERRITE BEAD

FB9909 071G 55 29 FERRITE BEAD

FB9908 095G 90 23 JUMP WIRE - -

FB9901 095G 90 23 JUMP WIRE - -

J924 095G 90 23 JUMP WIRE - -

J906 095G 90 23 JUMP WIRE - -

J931 095G 90 23 JUMP WIRE - -

J901 095G 90 23 JUMP WIRE - -

J920 095G 90 23 JUMP WIRE - -

J902 095G 90 23 JUMP WIRE - -

J914 095G 90 23 JUMP WIRE - -

J915 095G 90 23 JUMP WIRE - -

J909 095G 90 23 JUMP WIRE - -

J919 095G 90 23 JUMP WIRE - -

J911 095G 90 23 JUMP WIRE - -

J917 095G 90 23 JUMP WIRE - -

J904 095G 90 23 JUMP WIRE - -

J912 095G 90 23 JUMP WIRE - -

J903 095G 90 23 JUMP WIRE - -

J910 095G 90 23 JUMP WIRE - -

L9901 073G 174241 X LINE FILTER 18MH MIN EF20 3LFEF2022-303M

L9902 373G0174303X00 LINE FILTER 18MH MIN 1.26 3LFT18106-183

L9101 373G0253247X00 CHOKE COIL 3UH 15% DR8*8 5A

L8101 373G0253258X00 BOOST CHOKE 33UH 10% 3.5A 3LCEF16-330K

TRANSISTOR

Q8104 357G0600A01 MOSFET AOTF4126 19A 100V 42W TO-220F

Q9101 357G0667650004 MOSFET TK8A65D(STA4,X,M) 8A 650V SC-67

Q8107 057G 417511 MMBT3904

Q8105 057G 417511 MMBT3904

Q8106 057G 417517 TRA LMBT3906LT1G -200MA/-40V SOT-23 LRC

Q8101 357G0763060001 MOSFET AO4440 5A 60V SOIC-8

Q8103 357G07630620HF HF MOSFET 2N7002K_R1_00001 0.3A 60V

RESISTOR

R8138 061G0805000 JT RST 0805 0.05R MAX 1/8W

R9175 061G0805000 JT RST 0805 0.05R MAX 1/8W

R9176 061G08051002FT RST CHIP 10K 1/8W 1%

R8134 061G08051003FT RST CHIP 100K 1/8W 1%

R9114 061G08051003FT RST CHIP 100K 1/8W 1%

R8128 061G0805101 JT RST CHIP 100R 1/8W 5% TZAI YUAN

R8127 061G0805101 JT RST CHIP 100R 1/8W 5% TZAI YUAN

R8147 061G0805103 JT RST 0805 10K 5% 1/8W

R8129 061G0805103 JT RST 0805 10K 5% 1/8W

R8120 061G0805103 JT RST 0805 10K 5% 1/8W

R8119 061G0805103 JT RST 0805 10K 5% 1/8W

R9146 061G08051501FT RST CHIPR 1K5 +-1% 1/8W TZAI YAUN

R8131 061G08051502FT RST CHIP 15K 1/8W 1%

R8133 061G0805153 JT RST CHIP 15K 1/8W 5% TZAI YUAN

R9174 061G0805202 JT RST CHIP 2K 1/8W 5% TZAI YUAN

R9104 061G0805220 JT RST CHIPR 22OHM +-5% 1/8W TZAI YUAN

R9173 061G08052201FT CHIP 2K2 1/8W 1%

Brand	Sharp
Model	LC-42LB261U
Category	LED TV
Language	English

Sharp LC-42LB261U Service Manual
