Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
96
R8130 061G0805224 JT RST CHIPR 220K +-5% 1/8W TZAI YUAN
R9150 061G08052491FT RST CHIP 2K49 1/8W 1%
R8108 061G0805331 JT RST CHIP 330R 1/8W 5% TZAI YUAN
R8104 061G0805470 JT RST CHIPR 47OHM +-5% 1/8W TZAI YUAN
R8122 061G0805473 JT RST CHIPR 47K +-5% 1/8W TZAI YUAN
R8116 061G08055102FT RST CHIP 51K 1/8W 1%
R8135 061G08055102FT RST CHIP 51K 1/8W 1%
R8118 061G0805512 JT RST CHIPR 5K1 +-5% 1/8W TZAI YUAN
R8132 061G08056201FT RST CHIPR 6.2KOHM +-1% 1/8W TZAI YUAN
R8117 061G08056201FT RST CHIPR 6.2KOHM +-1% 1/8W TZAI YUAN
R9106 061G0805680 JT RST CHIPR 68OHM +-5% 1/8W TZAI YUAN
R9113 061G12060007JT RST CHIPR MAX 0R05 1/4W 1206
RJ902 061G12060007JT RST CHIPR MAX 0R05 1/4W 1206
R8153 061G12061008FT RST CHIPR 1OHM +-1% 1/4W TZAI YUAN
R8155 061G12061008FT RST CHIPR 1OHM +-1% 1/4W TZAI YUAN
R8154 061G12061008FT RST CHIPR 1OHM +-1% 1/4W TZAI YUAN
R9161 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9162 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9163 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9107 061G1206103 JT RST CHIPR 10KOHM +-5% 1/4W TZAI YUAN
R8112 061G1206103 JT RST CHIPR 10KOHM +-5% 1/4W TZAI YUAN
R9101 061G1206184 JT RST CHIPR 180K +-5% 1/4W TZAI YUAN
R9102 061G1206184 JT RST CHIPR 180K +-5% 1/4W TZAI YUAN
R9103 061G1206184 JT RST CHIPR 180K +-5% 1/4W TZAI YUAN
R9120 061G1206394 JT RST CHIPR 390K +-5% 1/4W TZAI YUAN
R9115 061G1206394 JT RST CHIPR 390K +-5% 1/4W TZAI YUAN
R9119 061G1206394 JT RST CHIPR 390K +-5% 1/4W TZAI YUAN
R9118 061G1206394 JT RST CHIPR 390K +-5% 1/4W TZAI YUAN
R9121 061G1206394 JT RST CHIPR 390K +-5% 1/4W TZAI YUAN
R9116 061G1206394 JT RST CHIPR 390K +-5% 1/4W TZAI YUAN
R9109 061G1206471 JT ST CHIPR 470 OHM +-5% 1/4W TZAI YUAN
R9112 061G1206479 JT RST 1206 4.7R 5% 1/4W
R9904 061G12066803FT RST CHIP 680K 1/4W 1%
R9905 061G12066803FT RST CHIP 680K 1/4W 1%
R9902 061G12066803FT RST CHIP 680K 1/4W 1%
R9901 061G12066803FT RST CHIP 680K 1/4W 1%
R9906 061G12066803FT RST CHIP 680K 1/4W 1%
R9903 061G12066803FT RST CHIP 680K 1/4W 1%
R8151 361G12069107FT RST 1206 0.91R 1% 1/4W SMD12060R91FT
R8152 361G12069107FT RST 1206 0.91R 1% 1/4W SMD12060R91FT
R9111 361G2SWJ24852T00TZ RST NWR 0.24R 5% 2W NKNP2WS0R24JT52
R8101 361G2SWJ50752T00YG RST WD 0R05 5% 2W NKN2WSJT-52-0R05
RJ901 061G12060007JT RST CHIPR MAX 0R05 1/4W 1206
RV9902 361G0046621KZE VARISTOR 620V 10%
RV9901 361G0046621KZE VARISTOR 620V 10%
NR9902 361G0058259MYW006A NTCR 2.5R 20% 3.1W SCK132R56MTY504
NR9901 361G0058259MYW006A NTCR 2.5R 20% 3.1W SCK132R56MTY504
IC
IC9102 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4
IC9151 056G 158501 IC AS431AN-E1 SOT23
IC9101 356G0379008231 AC/DC TPV002AS SOP-8
IC8501 356G0700008054 LED DRIVER PF7903BS SOP-8
OTHERS
CN8101 311GW200A06ABX WAFER 2.0MM 6P
