32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
97
CN9101 311GW200C16ABX CONN 2.0MM 16P R/A -
CN9901 387G050147F0ST AC R/A 2P 12.81MM
E715 715G6896P01000003H POWER BOARD PCB
FOR T9101 006G 31 4 1.7MM RIVET
FOR CN9901 006G 31500 EYELET
FOR L9902 006G 31502 EYELET
FOR NR9901 006G 31502 EYELET
FOR L9901 006G 31502 EYELET
FOR NR9902 006G 31502 EYELET
GND4 009G6005 1 GND TERMINAL
GND3 009G6005 1 GND TERMINAL
GND1 009G6005 1 GND TERMINAL
HS8101 Q90G0219002A0000HG HEAT SINK
HS9151 Q90G0219003A0000SY HEAT SINK
HS9101 Q90T0237 1 HEAT SINK
SG902 362G0010501MIT SPARK GAP 500V -20/+30%
SG903 362G0010501MIT SPARK GAP 500V -20/+30%
SG904 362G0010501MIT SPARK GAP 500V -20/+30%
T9101 380GL32P141N00 X'FMR 360UH 10% 5UH ER31 -
ZD9101 393G039SA2800T ZENER BZT52-B36 36V -- --
ZD9102 393G039SA2800T ZENER BZT52-B36 36V -- --
ZD9152 393G039SA2900T ZENER BZT52-B15 15V 0.41 SOD-123
705TAE57039 TRANSISTOR ASSY (Q9101 ASSY)
0M1G1730 8120 SCREW
705TAE93021 TRANSISTOR ASSY (D9151 D9152 ASS"Y)
0M1G1730 8120 SCREW
705TAE57038 TRANSISTOR ASSY (Q8104 ASSY)
0M1G1730 8120 SCREW
Z40G0002ALL01A OTHER LABEL
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
KEY BOARD
LOCATION PART NO. DESCRIPTION
WHOLE-ASSEMBLY KEPFEXA3 KEY BOARD
RESISTOR
R02 061G12061502FT RST CHIP R 15K 1/4W 1%
R05 061G12062401FF RST CHIPR 2.4KOHM +-1% 1/4W FENGHUA
R01 061G12062702FY RST CHIP R 27KOHM 1/4W +/-1%
R04 361G12064701FT RST 1206 4.7K 1% 1/4W SMD12064K7F
R07 361G12066800FT RST 1206 680R 1% 1/4W SMD1206680RF
R06 361G12066800FT RST 1206 680R 1% 1/4W SMD1206680RF
R03 361G12068201FF RST 1206 8.2K 1% 1/4W RS-06K822FT
OTHERS
CN01 033G8032 4F S HR CONNECTOR
E715 715G6715K0A002004I KEY BOARD PCB
SW01 077G 607 2 CJ CHIP TACT SWITCH
SW03 077G 607 2 CJ CHIP TACT SWITCH
SW07 077G 607 2 CJ CHIP TACT SWITCH
SW05 077G 607 2 CJ CHIP TACT SWITCH
SW02 077G 607 2 CJ CHIP TACT SWITCH
SW06 077G 607 2 CJ CHIP TACT SWITCH
SW04 077G 607 2 CJ CHIP TACT SWITCH
040G 45762420A LABEL 25X6MM
709T67150XS001 COMSUMPTIVE ASSY
IR BOARD
