Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
98
LOCATION PART NO. DESCRIPTION
WHOLE-ASSEMBLY IRPFCAB4 IR BOARD
C201 065G060310432K F CAP CHIP 0603 0.1UF K 50V X7R
CN201 033G8032 5F S HR CONNECTOR
CN201 311GW125D05ACX WAFER 1.25MM 5P V/T S1315-05SVB-S03-R
E715 715G5704R01000004S IR BOARD PCB
E715 715G5704R01000004X IR BOARD PCB
LED201 081G 14 24 EL CHIP LED BLUE/DARK RED
LED201 081G 14 24 GP CHIP LED (BR) GPTD1210BRC-D
R201 061G0603153 JY RST CHIPR 15KOHM 1/10W YAGEO
R203 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
R202 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
U201 356GS927057 IR RECEIVER IRM-H938M3/TR2 38 KHZ 6V
040G 45762420A LABEL 25X6MM
709T57040XS001 COMSUMPTIVE ASSY
