Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
99
Customer Model LC-42LB261U
TPV Model E42E41NKFMBSNNX
LOCATION PART NO. DESCRIPTION
PANEL LCA420HVN07ADS2R0X PANEL TPT420H2-HVN07 S370B XM TPV
MAIN BOARD
LOCATION PART NO. DESCRIPTION
WHOLE-ASSEMBLY 756TXECB01K008000X MAIN BOARD-CBPFE3SKX4
CAPACITOR
C602 067G315M1016HV EC 100UF 20% 35V 8*7
C603 067G315M1016HV EC 100UF 20% 35V 8*7
C185 067G315M1016HV EC 100UF 20% 35V 8*7
C710 065G040210131J F CAP 0402 100PF 5% 50V NP0
C649 065G040210131J F CAP 0402 100PF 5% 50V NP0
C632 065G040210131J F CAP 0402 100PF 5% 50V NP0
C701 065G040210131J F CAP 0402 100PF 5% 50V NP0
C643 065G040210131J F CAP 0402 100PF 5% 50V NP0
C646 065G040210131J F CAP 0402 100PF 5% 50V NP0
C650 065G040210131J F CAP 0402 100PF 5% 50V NP0
C156 065G040210131J F CAP 0402 100PF 5% 50V NP0
C749 065G040210131J F CAP 0402 100PF 5% 50V NP0
C180 065G040210232K F CAP 0402 1NF 10% 50V X7R
C702 065G040210232K F CAP 0402 1NF 10% 50V X7R
C432 065G040210232K F CAP 0402 1NF 10% 50V X7R
C628 065G040210232K F CAP 0402 1NF 10% 50V X7R
C431 065G040210232K F CAP 0402 1NF 10% 50V X7R
C133 065G040210232K F CAP 0402 1NF 10% 50V X7R
C104 065G040210232K F CAP 0402 1NF 10% 50V X7R
C161 065G040210232K T CAP 0402 1NF 10% 50V X7R UMK105 B7102KV
C160 065G040210232K T CAP 0402 1NF 10% 50V X7R UMK105 B7102KV
C159 065G040210232K T CAP 0402 1NF 10% 50V X7R UMK105 B7102KV
C166 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%
C135 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C171 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C170 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C163 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C167 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C403 065G040210412K F CAP 0402 100NF 10% 16V X7R
C404 065G040210412K F CAP 0402 100NF 10% 16V X7R
C402 065G040210412K F CAP 0402 100NF 10% 16V X7R
C636 065G040210412K F CAP 0402 100NF 10% 16V X7R
C743 065G040210412K F CAP 0402 100NF 10% 16V X7R
C415 065G040210412K F CAP 0402 100NF 10% 16V X7R
C719 065G040210412K F CAP 0402 100NF 10% 16V X7R
C627 065G040210412K F CAP 0402 100NF 10% 16V X7R
C433 065G040210412K F CAP 0402 100NF 10% 16V X7R
C434 065G040210412K F CAP 0402 100NF 10% 16V X7R
C429 065G040210412K F CAP 0402 100NF 10% 16V X7R
C425 065G040210412K F CAP 0402 100NF 10% 16V X7R
C427 065G040210412K F CAP 0402 100NF 10% 16V X7R
C426 065G040210412K F CAP 0402 100NF 10% 16V X7R
C623 065G040210412K F CAP 0402 100NF 10% 16V X7R
C622 065G040210412K F CAP 0402 100NF 10% 16V X7R
C742 065G040210412K F CAP 0402 100NF 10% 16V X7R
