8. PICTURE ADJUSTMENT
8.1 White Balance
• Change source to HDMI
• Load 80% White pattern from signal generator
• Enter Factory Menu by pressing MENU + 1147
• Choose 3 Picture
• Choose 3 W/B Adjust
• In 0 WB Mode choose Warm/Normal/Cold
• Change R-Gain/G-Gain/B-Grain to meet specication
Color Temperature specication:
x y °K Deviation
Cold 0,2718 0,2776 12000 ±0.003
Normal 0,2848 0,2932 9300 ±0.003
Warm 0,3135 0,3236 6500 ±0.003
