13
LC-43LBU591U / LC-50LBU591U / LC-55LBU591U / LC-65LBU591U
LC-43LBU591C / LC-50LBU591C / LC-55LBU591C / LC-65LBU591C
3 Attach the wall-mount bracket to your TV using the mounting holes on the back of your TV. See the instructions that
came with the wall-mount bracket for information about how to correctly hang your TV.
Notes
• The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. See the instructions that came with the
wall-mount bracket for screw lengths.
• The mounting holes on the back of your TV take type M6 screws.
7.87 in. (200 mm)
7.87 in. (200 mm)
43"/50"/55" models
55" model shown
15.75 in. (400 mm)
15.75 in. (400 mm)
65" model
