Sharp LC-46E77U - Page 107

LC-46/52E77U
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[6] CABINET AND MECHANICAL PARTS (LC-46E77U)
1 CCABAC226WJ01 CA N X Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 Not Available - N - Bottom Decoration A Ass'y
1-2-1 Not Available - N - Bottom Decoration A
1-2-2 HBDGBA061WJSA AH J SHARP Badge
1-3 Not Available - - Bottom Decoration B Ass'y
1-3-1 Not Available - N - Bottom Decoration B Ass'y
1-3-2 HDECSA057WJ3A AM N X Shine Trim
1-4 Not Available - - LED Cover
1-5 TLABZC190WJZZ AG N X Pop Label
1-6 XEBS740P10000 AB J Screw, x14
2 CCABBB434WJ01 BN N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPD214WJSA AF N X Terminal label
3 CCOVAC951WJ02 AK N X Side AV Cover Ass'y
3-1 Not Available - N - Side AV Cover
3-2 Not Available - N - Side AV Label
4 CCOVAC952WJ01 AK X Key Button Cover Ass'y
4-1 Not Available - N - Key Button Cover
4-2 Not Available - N - Control Button Label
5 CSLDMB612WJ01 AV X Control Shield Ass'y
5-1 Not Available - N - Control Shield
5-2 PRDARA644WJFW AP X Control Radiator
5-3 XBPS730P06WS0 AA J Screw(for Radiator), x6
6 GCOVAC576WJKZ AC J Vesa Hole Cover, x4
7 GCOVAD282WJ3A AN X Bottom Cover
8 HINDPD127WJSA AD N X Model Label
9 LANGKB834WJFW AU X Support Angle, x2
10 LANGKC082WJFW AC X MAIN PWB Angle
11 LHLDFA036WJKZ AB J Wire Holder(for Power PWB), x3
12 LHLDWA133WJKZ AC J Wire Holder, x2
13 LHLDWA151WJKZ AB J Wire Holder
14 LHLDWA172WJKZ AD J Wire Holder
15 LHLDWA175WJUZ AC J
Wire Holder, x2
16 NSFTZA284WJFW AC J Hexagon Nut, x4
17 PMLT-A593WJZZ AC X Gasket:8X35X7T, x5
18 PMLT-A594WJZZ AD X Gasket:8X50X7T, x5
19 PMLT-A597WJQZ AF X Gasket(TUNER)
20 PSLDMB560WJFW AR X MAIN PWB Shield
21 PSPAZB963WJKZ AD J Conductor(JACK), x2
22 PZETJA002WJZZ AH X Barrier Sheet
23 QCNCMA275WJQZ AC J Connecting Cord(MODEL SELECTOR), x2
24 QCNW-H776WJQZ AX X Connecting Cord(LW:MAIN-LCD)
25 QCNW-H812WJQZ AF X Connecting Cord(LA:POW-INV)
26 QCNW-H813WJQZ AF X Connecting Cord(PL:POW-LCD)
27 QCNW-H495WJPZ AL X Connecting Cord(SP:MAIN-SP(L/R))
28 QCNW-J129WJQZ AL X Connecting Cord(PD:MAIN-POW)
29 QCNW-J130WJQZ AH X Connecting Cord(LP:MAIN-LCD)
30 QCNW-J131WJQZ AH X Connecting Cord(LB1:MAIN-POW)
31 QCNW-J132WJQZ AF X Connecting Cord(LB2:POW-INV)
32 QCNW-J133WJQZ AF X Connecting Cord(KM:MAIN-KEY)
33 QCNW-J134WJQZ AH X Connecting Cord(RA:MAIN-LED)
34 RSP-ZA413WJZZ AQ J Speaker(L)
35 RSP-ZA414WJZZ AQ J Speaker(R)
36 Not Available - - Bar Code Label
37 XBPS830P06000 AA J HDMI Screw, x4
38 XEBS740P08000 AB J Screw(FOR CAB-A), x8
39 XEBS930P10000 AA J Screw(S-VIDEO)
40 XEBS940P16000 AB J Screw(CAB-A/B), x8
41 XHPS830P06WS0 AA J Screw, x41
42 XHPS830P10WS0 AB J Screw(FOR CAB B), x4
43 XIPSN20P04000 AA J Screw(SIDE HDMI), x2
