Sharp LC-46E77U - Page 109

LC-46/52E77U
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] LCD MODULE Assembly (LC-46E77U)
1 R1LK460D3LW80Z EL N X 46"LCD Panel Module(LK460D3LW80Z2)
2 Not Available - - Bezel Ass'y
3 Not Available - - BL Chassis Ass'y
4 LHLDZA963WJKZ AB J Holder, x4
5 QSOCFA002WJZZ AD J Socket, x18
6 RLMPLA038WJN1 AR J Lamp, x18
7 CHLDZB349WJ01 AU J Lamp Holder Unit
8 CHLDZB350WJ01 AU J Lamp Holder Unit
9 PCOVUA113WJZZ BA J Diffusion Plate
10 PSHEPA873WJZZ AX J Lens Sheet
11 RUNTKA538WJN1 BF J Inverter Unit
12 RUNTKA539WJN1 BF J Inverter Unit
13 RUNTKA540WJZZ AP J GND-PWB
14 RUNTKA541WJZZ AP J GND-PWB
15 PCOVWA038WJKZ AM J Cover
16 PCOVWA039WJKZ AM J Cover
17 QPWBM0782TPZZ AG J FPC
18 QPWBM0783TPZZ AG J FPC
19 CPWBX4023TPXA BW J C-PWB (LCD Control Unit)
20 RCORFA061WJZZ AG J Ferrite Core, x2
21 XHPS830P06WS0 AA J Screw, x10 (for Inverter Unit x4, for Cover x6)
22 LX-HZA039WJF7 AB J Screw, x14 (for fixing Bezel Ass'y)
23 LX-HZA047WJF7 AB J Screw, x2 (for fixing Bezel Ass'y)
24 LX-HZA046WJF7 AB J Screw, x4 (for GND-PWB)
25 LX-HZA045WJF7 AB J Screw, x6 (for C-PWB)
