LC-46/52E77U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE266FM02 AH N X KEY Unit
N DUNTKE833FM03 CB N X MAIN Unit
N DUNTKF096FM01 AN N X R/C, LED Unit
N RDENCA336WJQZ BR X POWER Unit
N CPWBX4023TPXA BW N J LCD Control Unit (LC-46E77U)
N CPWBX4023TPXZ BW N J LCD Control Unit (LC-52E77U)
N RUNTKA538WJN1 BF N J INVERTER Unit-1 (LC-46E77U)
N RUNTKA539WJN1 BF N J INVERTER Unit-2 (LC-46E77U)
N RUNTKA528WJN1 BF N J INVERTER Unit-1 (LC-52E77U)
N RUNTKA529WJN1 BF N J INVERTER Unit-2 (LC-52E77U)
N RUNTKA540WJZZ AP N J INVERTER GND Unit-1 (LC-46E77U)
N RUNTKA541WJZZ AP N J INVERTER GND Unit-2 (LC-46E77U)
N RUNTKA530WJZZ AP N J INVERTER GND Unit-1 (LC-52E77U)
N RUNTKA531WJZZ AP N J INVERTER GND Unit-2 (LC-52E77U)
[2] LCD PANEL
N R1LK460D3LW80Z EL N X 46"LCD Panel Module(LK460D3LW80Z2)
N R1LK520D3LW80Z EY N X 52"LCD Panel Module(LK520D3LW80Z2)
[3] DUNTKE266FM02 (KEY Unit)
D151 RH-EX0646GEZZY AA J MTZJT-7215B
D152 RH-EX0646GEZZY AA J MTZJT-7215B
D155 RH-EX0646GEZZY AA J MTZJT-7215B
P151 QPLGNA059WJZZ AC J PLUG
R151 VRD-RA2BE822JY AA J 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J SWITCH
S152 QSW-K0003AJZZ+ AB J SWITCH
S153 QSW-K0003AJZZ+ AB J SWITCH
S154 QSW-K0003AJZZ+ AB J SWITCH
S155 QSW-K0003AJZZ+ AB J SWITCH
S156 QSW-K0003AJZZ+ AB J SWITCH
S157 QSW-K0003AJZZ+ AB J SWITCH
[4] DUNTKE833FM03 (MAIN Unit)
C501 VCKYCY1AB105KY AB J 1 10V Ceramic
C503 VCKYCY1AB105KY AB J 1 10V Ceramic
C504 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C505 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C506 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C507 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C508 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C509 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C510 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C512 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C514 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C515 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C516 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C517 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C519 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C520 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C521 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C522 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C523 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C525 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C533 VCCCCZ1HH471JY AA J 470p 50V Ceramic
C535 VCKYCY1AB105KY AB J 1 10V Ceramic
C536 VCCCCZ1HH471JY AA J 470p 50V Ceramic
C537 VCCCCZ1HH471JY AA J 470p 50V Ceramic
C539 VCCCCZ1HH471JY AA J 470p 50V Ceramic
C540 VCKYCY1AB105KY AB J 1 10V Ceramic
C555 VCKYCY1AB105KY AB J 1 10V Ceramic
C557 VCKYCY1AB105KY AB J 1 10V Ceramic
C563 VCKYCY1EB103KY AA J 0.01 25V Ceramic
C565 VCKYCZ1EF104ZY AA J 0.1 25V Ceramic
C566 RC-KZA403WJPZY AB J CAPACITOR
C569 VCKYCY1AB105KY AB J 1 10V Ceramic
C570 VCKYCY1AB105KY AB J 1 10V Ceramic
C575 VCCCCZ1HH150JY AB J
15p 50V Ceramic
C576 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C577 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C578 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C579 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C580 VCCCCZ1HH150JY AB J 15p 50V Ceramic
C1101 RC-KZA616WJQZY AB J CAPACITOR
C1102 RC-KZA616WJQZY AB J CAPACITOR
C1107 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C1112 RC-KZA510WJPZY AB J CAPACITOR
C1116 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C1119 VCKYCZ1AB473KY AB J 0.047 10V Ceramic
C1124 VCKYCZ1EB472KY AB J 4700p 25V Ceramic
C1125 VCKYCY1AB105KY AB J 1 10V Ceramic
C1126 VCKYCY1EB104KY AB J 0.1 25V Ceramic
