6. UPGRADING INSTRUCTIONS
6.1 Introduce for MSD6488 chip
6.1.1 Type of MS6488 chip
Chip type Demod DDR Area Function
6488EVE DVBT/C 8Gbit EU/AU Hbbtv/ Browser/APP
6488MVE DVBT/C 8Gbit EU/AUB Hbbtv/Browser/APP, inset
MEMC
6.1.2 Hardware
Chip type MS6488
Chip MS6488EV/MS6488MV
External DDR 1GByte
Flash 512MByte
Tuner R842/RT710
APM 5707/5711
EXT demod 102KA/102KT
SD Cardexuan optional
WIFI 7603/8188/7632(support Bluetooth)
CI optional
Note:
Flash detail:
size brand ash type
512MB MXIC MX30LF4G18AC-TI
External DDR detail:
size brand ash type
1GB NANYA NT5CB128M16IP-EK
6.2 Chip alias
Chip CVTE Name MSTAR Name
6488EV Muji 6488
6488MV Manhattan 6488E
6.3 Upgrading Instruction
6.3.1 The rules of USB upgrade le name
Because the software is not compatible between the chip, so can't rise each other, we use soft-
ware name distinguish it.
6488EV: allupgrade_6488.bin
6488.U701 use 6488EV chip
6488MV: allupgrade_6488m.bin
6488.U801, 6488.U703, 6488.U731 use 6488MV chip

Sharp LC-49CUF8472ES Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	49 \
Display brightness	280 cd/m²
Display technology	LED
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Display diagonal (metric)	123 cm
Motion interpolation technology	-
3D	No
Supported file systems	FAT16, FAT32, NTFS
Annual energy consumption	130 kWh
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	140 W
Power consumption (standby)	0.5 W
Power consumption (typical)	115 W
Power consumption (PowerSave)	89 W
Tuner type	Analog & digital
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Audio decoders	DTS, Dolby Digital, DTS Studio Sound, Dolby Digital Plus
RMS rated power	20 W
Number of speakers	2
Video apps	YouTube
Product color	Black
Panel mounting interface	600 x 300 mm
Audio formats supported	AAC, AC3, EAC3, LPCM, M4A, MP3, OGG, WMA
Image formats supported	BMP, JPEG, JPG, PNG
Video formats supported	ASF, AVI, FLV, M2TS, M4V, MKV, MP4, MPG, RM, RMVB, SWF, TS, VOB, WMV
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Certification	CE, CB
Package depth	138 mm
Package width	1205 mm
Package height	735 mm
Package weight	15100 g
