28
LC-39/50LE750
LC-39/50LE751
LC-39/50LE752
2. Removing of major Parts 50”
2.1. Remove the 4 lock screws and detach the Stand.
2.2. Remove the 14 lock screws , 1 lock screw , 1 lock screw  and detach the AC cord cover and Rear Cabinet
1 / 5
STAND
2
front
CABINET
rear
CABINET
1
3
4
STAND
