LC-C4067U/N,LC-40E67UN,LC-40/46/52E77UN,LC-C46/5277UN,LC-46/52SB57UN
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[6] CABINET AND MECHANICAL PARTS (LC-46E77UN)(LC-C4677UN)
1 CCABAC226WJ01 BY N X Front Cabinet Ass'y (LC-46E77UN)
1 CCABAC226WJ03 BV N X Front Cabinet Ass'y (LC-C4677UN)
1-1 Not Available - - Front Cabinet
1-2 Not Available - N - Bottom Decoration A Ass'y
1-2-1 Not Available - N - Bottom Decoration A
1-2-2 Not Available - - SHARP Badge
1-3 Not Available - - Bottom Decoration B Ass'y
1-3-1 Not Available - N - Bottom Decoration B
1-3-2 HDECSA057WJ3A AM N X Shine Trim
1-4 Not Available - - LED Cover
1-6 XEBS740P10000 AB J Screw, x14
2 CCABBB434WJ01 BN N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPD214WJSA AF N X Terminal label
3 CCOVAC951WJ02 AK N X Side AV Cover Ass'y
3-1 Not Available - N - Side AV Cover
3-2 Not Available - N - Side AV Label
4 CCOVAC952WJ01 AK X Key Button Cover Ass'y
4-1 Not Available - N - Key Button Cover
4-2 Not Available - N - Control Button Label
5 CSLDMB612WJ01 AV X Control Shield Ass'y
5-1 Not Available - N - Control Shield
5-2 PRDARA644WJFW AP X Control Radiator
5-3 XBPS730P06WS0 AA J Screw (for Radiator), x6
6 GCOVAC576WJKZ AC J VESA Hole Cover, x4
7 GCOVAD282WJ3A AN X Bottom Cover
8 HINDPD348WJSA AD N X Model Label (LC-46E77UN)
8 HINDPD351WJSA AD N X Model Label (LC-C4677UN)
9 LANGKB834WJFW AT X Support Angle, x2
10 LANGKC082WJFW AC X MAIN PWB Angle
11 LHLDFA036WJKZ AB J Wire Holder (for Power PWB), x3
12 LHLDWA133WJKZ AC J Wire Holder, x2
13 LHLDWA151WJKZ AB J Wire Holder
14 LHLDWA172WJKZ AD J
Wire Holder
15 LHLDWA175WJUZ AC J Wire Holder, x2
16 NSFTZA284WJFW AC J Hexagon Nut, x4
17 PMLT-A593WJZZ AC X Gasket:8X35X7T, x5
18 PMLT-A594WJZZ AD X Gasket:8X50X7T, x5
19 PMLT-A597WJQZ AF X Gasket (Tuner)
20 PSLDMB560WJFW AR X MAIN PWB Shield
21 PSPAZB963WJKZ AD J Conductor (Jack), x2
22 PZETJA002WJZZ AH X Barrier Sheet
23 QCNCMA275WJQZ AC J Connecting Cord (MODEL SELECTOR), x2
24 QCNW-H776WJQZ AX X Connecting Cord (LW:MAIN-LCD)
25 QCNW-H812WJQZ AF X Connecting Cord (LA:POW-INV)
26 QCNW-H813WJQZ AF X Connecting Cord (PL:POW-LCD)
27 QCNW-H495WJPZ AL X Connecting Cord (SP:MAIN-SP(L/R))
28 QCNW-J463WJQZ AK X Connecting Cord (PD:MAIN-POW)
29 QCNW-J130WJQZ AH X Connecting Cord (LP:MAIN-LCD)
30 QCNW-J131WJQZ AH X Connecting Cord (LB1:MAIN-POW)
31 QCNW-J132WJQZ AF X Connecting Cord (LB2:POW-INV)
32 QCNW-J133WJQZ AF X Connecting Cord (KM:MAIN-KEY)
33 QCNW-J134WJQZ AH X Connecting Cord (RA:MAIN-LED)
34 RSP-ZA413WJZZ AQ J Speaker (L)
35 RSP-ZA414WJZZ AQ J Speaker (R)
36 TLABK0023TAZZ AA J Bar Code Label
37 XBPS830P06000 AA J HDMI Screw, x4
38 XEBS740P08000 AB J Screw (for CAB-A), x8
39 XEBS930P10000 AA J Screw (for S-Video)
40 XEBS940P16000 AB J Screw (for CAB-A/B), x8
41 XHPS830P06WS0 AA J Screw, x41
42 XHPS830P10WS0 AB J Screw (for CAB-B), x4
43 XIPSN20P04000 AA J Screw (for Side HDMI), x2
